Hot sales cylinder body bushing boring machine T8120D*20
- Category: >>>
- Supplier: Xian Amco Machine Tools Co. Ltd.
Share on (60346044882):
Product Overview
Description
Produt Description
Hot sales cylinder body bushing boring machine T8120D*20
Model T8120x20 and T8115Bx16 cylinder body bushing boring machines are repairing machine tools with high efficiency and high precision. Which were developed in our factory. They can be used for boring master bushing and can bushing of engine & generator’s cylinder body in automobiles, tractors and ships etc. if necessary, the flywheel hub bore and bushing seat hole can be also finely bored. In order to reduce auxiliary manhours and labour intensity and guarantee machining quality, accessories for centering, Align cutter gauge, measuring inner diameter, boring rod bracket, tool holder to increase diameter, boring tool micro-adjuster can be provided with the main machine.
Main Specifications
Model | T8115Bx16 | T8120Dx20 | T8120Ax20 | LB2300 | |
Dia. Range of boring hole mm | F 36 – F 150 | F 36 – F 200 | F 28 – F 225 | F 22 – F 250 | |
Max. length of cylinder body | 1600mm | 2000mm | 2250mm | 2300mm | |
Main shaft max length | 300mm | 550mm | |||
Main shaft rotating speed | 210-945rpm ( 6 steps) | I:30~150rpm II:93-467rpm | 30-467rpm stepless | ||
Boring rod feed quantity mm/rad | 0.044, 0.167 | 0.43;0.085;0.125 | 0.044;0.078;0.121;0.176 | ||
Motor Power | 0.75kw / 1.1kw | 1.5kw | 1.5kw | ||
Stepless regulating speed + Synchronous belt wheel (Optional) | Main shaft rotating speed (stepless) | 30-467r/min | / | / | |
Boring rod feed quantity
| 0.044, 0.167mm/rad | / | / | ||
Motor Power | 1.5kw | / | / | ||
Accessories Detailed
Align cutter gauge, Align center gauge, Cylinder clamping device, boring bar, coring cutter
Our exhibition
Packaging&Shipping
Capital market
Certifications
Company
Xi’an AMCO Machine Tools Co., Ltd is a professional company who are specialized in producing, researching and developing and supplying all kinds of Machines and equipments. The products concerned include five series, they are Metal Spinning series, Punch and Press series, Shear and Bending series, Circle rolling series, Other special Forming series.
With several year experience in this field, AMCO machine tools has gained a deeply understanding of the quality of the machine in famous domestic manufacture, it help us to supply the most proper machine according to customer different requirements.
We had passed ISO9001 quality control certificates. All products are produced according to exporting standard and conform to the inspection standard of exported product of the People republic of China. And some products has passed CE certificate.
