RF connector n male for 1/2 cable raw lowest best zhenjiang factory price

Specification

Impedance

 50 Ω

Vibration

100m/s (10-500Hz), 10g

Temperature Range

 -55 to +155°C

Frequency

 DC to 11GHZ

Working Voltage

1000V r.m.s

Withstanding Voltage

2500V r.m.s

Contact Resistance

Center contact

≤1m Ω

Outer contact

 ≤1m Ω

Insertion Loss

≤0.24dB @ 6GHz

Insulation resistance

≥5000 M ohm

Center Conductor Retention Force

 ≥0.56N

Voltage Standing Wave Ratio

Straight

≤1.15/6GHz

Right angle

≤1.25/6GHz

Durability(mating)

≥500cycles

MATERIAL AND PLATING

Body

Brass

Nickel plated

Pin Contact

Brass

Gold plated

Socket Contact

Beryllium or tin bronze

Gold plated

Resilient Contact

Beryllium-copper

Gold plated

Insulator

PTFE

Crimp Ferrule

Copper alloy

Nickel or gold plated

O-ring Sealing

6146 silicon rubber
