Product Overview

Description

Descriptions:

The AE-Y307 series thermostat is a stand-alone microprocessor based thermostat with LCD display. The thermostats are designed mainly to control room temperature by way of on/off controlling the fan coil units(with or without motorised valves), air damper or electric heaters in heating, cooling and ventilation applications.

Models are available for heating/cooling/ventilation control of 2-pipe or 4-pipe fan coil units.

It is widely used in the civil architecture such as hotel, office building, supermarket, factory, hospital, villa, etc.



Specifications:

Sensing element: NTC thermostor

Supply voltage: 110VAC/220VAC available. If you need other voltage, please contact me.

Mounting hole distance: 60mm(standard).

Dimension: 86*86*13.5mm

Connection wire diameter: Max 0.8mm

Housing: Flame retarding ABS.

Accuracy: ±1degree Celsius.

Set-point Range: 5~35 degree Celsius.

Load: below 3A

Power consumption: below 2W

Max load: 400w

Display: LCD



Product Features:

1. Large LCD dual display of room temperature and user pre-set temperature, easy to operate and simple for installation.

2. Key-lock function

3. Time display

4. Reset function

5. Adjustable High/Medium/Low fan speed and dynamic fan speed display.

6. Standard 86x86 dimensions with thickness only 13mm

7. AE-Y307L with blue back light

AE-Y307Y with remote control function

AE-Y307YL with blue back light and remote control function.



Wiring Diagram:

AE-Y307B                                                                  AE-Y307DA/DB

to control fan coil only                                              to control fan coil with 3-wire

                                                                                 motorised valve





AE-Y307DA/DB                                                      AE-Y307F

to control fan coil with 2-wire                                to control 2-position air damper

motorised valve





Product Displaying:
