Two detecting Motion Sensor 433mhz Wireless Indoor Pet Immunity Pir Sensor

Share on (60348054370):


Price:$6.00 - $6.50

Quantity:


Product Overview

Description


Saful wireless/wired PIR gsm alarm Pet Immune PIR 433 mhz

Product Description



1.Rainproof design for outdoor, IP Grade is IP65;
2.Duilt-in 2 newly-developed dual element passive infrared sensor unit;
Intelligent MCU inside, increased anti-light interference and eliminate false alarm;
3.Adopts Pet Immunity technology &specialized optical lens for eliminate false alarm;
4.Microcontroller temperature analysis and Automatic temperature compensation for best summertime detection;
5.Tightly-mated bug guard to protect the sensor optics from insects, spiders and dust;
6.Selectable detection sensitivity (up to 8 sensitivity levels for choosing) for different environmental requirements;
7.Internal Wireless Antenna, long distance transmission;Wireless transmitting digital signal to control panel;
8.Learning code, easy to assign to the alarm panels;Tamper Switch for protecting the to avoid opened;SMT adopted, RF and EMI Immunity;
9.Low power consumption, backup rechargeable battery;





Packaging & Shipping



Size: 245mm *145mm * 90mm (W*H*D)
Weight: 0.85Kg





Technical Parameters



Operating Voltage

12VDC(Powered Up by Solar Panel)

Detection Range

Vertical angle 60degree, Horizontal angle 110 degree, 12m at 20°C.

Standby Current

less than 100uA

Alarm Current

less than 30mA

RF Immunity

> 30V/m 0.1-500MHz

Sensitivity

> 3300V/W

Noise(Vp-p)

<200mV, (mVp-p)(25°C)

Anti white light

>10000Lux

Transmitting Freq.

433.92MHz

Transmitting Distance

minimum 100m( in the open area)

Pet Immunity

25Kg

Temperature Range

-20°C ~ +55°C

Relative Humidity

95% (25 °C)

Installation Mode

Wall mounted by bracket

Backup Battery

3*1.2V   AAA Ni-MH Rechargeable battery, can last up to 40days.

Installation Height

1.8~2.4m









 -4-1



FAQ

1. Q: Why to choose us?

     A: a. Original Factory, so we will give you the best price and aftersale service.

          b. ODM & OEM. We can customize the products as your requirement for free. (Only charge making cost)

          c. Fast delivery. 1-7 days after payment.

          d. Strict quality control. We test every single product before shipment.

          e. Perfect after-sale service. If you got any problem of te products, welcome to contact us any time.

          f. Low MOQ. We also accept small quantity orders to surport you. Sample order is okay too.

          g. Prompt Reply within 12 hours. Our sales are all graduated in the colleague. They are friendly, patience, honest and professional.

2. Q: What is the advantage of your products?

     A: We are professional manufacturer in this field with lots of years R&D and market research experience, we can provide competitive price and high quality products for you.

3. Q: Can you help us design or monify the products as we requestion?

     A: We have R&D capability and professional&efficient team, customized service and OEM/ODM are welcomed. We will try our best to satisfy you.

4. Q: What are the terms of Payments?

     A: L/C, T/T, Western Union, Paypal, Escrow and Cash

Certification

CE-alarm and video door phoneFCC RoHS -gsm alarm system



Company Information

600 522.jpg

Shenzhen Top saful is a large scale R&D and manufactory enterprise of video door phone, gsm alarm, Metal detector and other security products. Our goods have passed CE, FCC, Rohs, C-tick certifications.  We can also do OEM/ODM as your designs too. Welcome to be our agents!
