Various models factory directly dc motor multi turn electric actuator motorized actuators

Product Overview

Description



1.Power Supply AC380V(±5%),AC220V(±5%)

2.Frequency 50Hz(±0.4%)

3.Ambient Temperature -20°C to +70°C Intelligent On-off Type and -20°C to +60°C Intelligent Adjusting Type

4.Ambient Humidity ≤95%(At25°C)

5.Height above sea level≤1000m

6.Input&Output signal 4-20mA

7.Basic Error ≤±1%

8.Travel Control repetiveness error≤±1%

9.Ingress protection IP67

10.Explosion Level ExdIIBT4

11.Model Representation Please check Form1-2

12.Inform us if special order



Model	Torque (Nm)	Max Stem Diameter (mm)	Manual Ratio	AC380V			AC220V			Approx Weight (kg)
				Output Speed (r/min)	Power (KW)	Current (A)	Output Speed (r/min)	Power (KW)	Current (A)
JIK3110	100	28	1:1	18	0.25	1.7	18	0.25	3.0	30
JIK3115	150	28	1:1	18	0.37	2.5	18	0.37	4.0	30
JIK3220	200	40	1:1	18/24	0.37/0.55	2.5/3.5	18	0.55	5.5	35
JIK3230	300	40	1:1	18/24	0.55/0.75	3.5/5.5	18	0.75	7.0	35
JIK3345	450	48	1:1	18/24	0.75/1.1	5.5/6.3				64
JIK3360	600	48	1:1	18/24	1.1/1.5	6.3/8.0				65
JIK3490	900	60	1:1	18/24	1.5/2.2	8.0/10				109
JIK3412	1200	60	1:1	18/24	2.2/3.0	10/11				110
JIK3518	1800	70	21.5:1	24	4.0	12				200
JIK3525	2500	70	21.5:1	24	5.5	15				203
JIK3635	3500	75	22.5:1	18	7.5	19				308
JIK3650	5000	75	22.5:1	18	11	23				310
JIK3780	8000	80	67.5:1	18	11	23				487
JIK37100	10000	100	67.5:1	18	13	29				490



Model	Torque (Nm)	Max Stem Diameter (mm)	Manual Ratio	AC380V			AC220V			Approx Weight (kg)
				Output Speed (r/min)	Power (KW)	Current (A)	Output Speed (r/min)	Power (KW)	Current (A)
JIK3110	100	28	1:1	18	0.25	1.7	18	0.25	3.0	30
JIK3115	150	28	1:1	18	0.37	2.5	18	0.37	4.0	30
JIK3220	200	40	1:1	18	0.37	2.5	18	0.55	5.5	35
JIK3230	300	40	1:1	18	0.55	3.5	18	0.75	7.0	35
JIK3345	450	48	1:1	18	0.75	5.5				64
JIK3360	600	48	1:1	18	1.1	6.3				65
JIK3490	900	60	1:1	12	1.5	8.0				109
JIK3412	1200	60	1:1	12	2.2	10				110
JIK3518	1800	70	21.5:1	12	3.0	11				200
JIK3525	2500	70	21.5:1	12	4.0	12				203
JIK3635	3500	75	22.5:1	12	5.5	15				308
JIK3650	5000	75	22.5:1	12	7.5	19				310



















































Specializing:

We are specializing in manufacturing pneumatic actuator, electric actuator, pneumatic actuated butterfly and ball valve, electric actuated butterfly and ball valve, Limited Switch box and other Accessories.........



Advantage:

1.Price:  As we are the professional manufacture in valve actuators and accessories, we ensure that the price offered must be very competitive compare with others.

2. Raw material inspection: All material test high quality, and keep in warehouse.

3. Workers: All workers training 3 monthes, skilled workers on production line.



Sample Order:

We will charge express fee only for old customers in generally, and for new customers we will charge 50% of the units cost and express fee mostly. (It can be discussed, we keep options always.)



Delivery Time:

We usually take 20days for official orders after received the prepayment, And Sample orders will be ready within 7days.



Quality Control:

 We got very strict and complete quality system to ensure that each product will meet quality requirements as per clients, incoming quality control, final quality control, out-going quality control. Meanwhile, all of the products will be strictly inspected before delivery.”’ Quality First, Service First’’ that we are pursuing All the time.



Warranty Period:

18 months from the date we signed the contract or PI. Technical support for the whole life.



Payment Terms And Conditions:

1. TT Terms: The payment will be 30% of prepayment by direct bank remittance (T/T),remaining 70% before Shipment or the copy of BL send by us Via Fax or Email.

2. L/C Terms: Payment by L/C at sight and Unrestricted. (L/C must allow 30days minimum from the shipment date of presentation of documents for negotiation, all the clauses within L/C must be clear, concise and acceptable. Do not allow special clauses, terms and conditions.)



Competitive Price:

We provide competitive price, good quality and best service to reach the win-win goal.



Customization:

custom-made is acceptable.

Q: Are you a manufacture or trading company?
A: We are a professional trading company engaging in the field of dc motor electric actuator motorized actuators products, and we have got permit of import and export as well.

Q: How can I get the sample? What's the lead time?
A: Samples could be sent within one week, the lead time is 10-15 days.

Q: How does your factory control product quality?
A: ISO9001 Certificated, independent quality control team with 16 inspectors in our factory. Thrid party certificated and factory audit accepted. Third party quality control accepted.



Q:Have dc motor electric actuator motorized actuators 100% assembled well in stock?
A: Yes,all dc motor electric actuator motorized actuators is available.



Q: Do you provide ODM/OEM service?
A: OEM/ODM is welcome,From the concept to finished goods, we do all (design, prototype reviewing, tooling and production) in the factory.
