Factory direct ac dc power converter 220v to 5v 30w
- Category: >>>
- Supplier: Nanjing Pengtu Power Supply Co. Ltd.
Share on (60350128928):
Product Overview
Description
ac dc power converter 220v to 5v 30w
Product Description
Features
l Wide input voltage
l Broadband noise filter of input
l Surge suppress circuit of input
l Comply with UL1950, IEC950 safety regulation
l Nice shape design
l Terminal connection method
l Fast dynamic response
Input Characteristic
l Inputvoltage range……………………176 ~ 264 VAC Rated value: 220VAC
Reverse Protection
Fuse Outside
Output Characteristic
l Voltage accuracy …….................…………±1%
l Line regulation(main) ………………........±0.2%
l Load regulation(main) …………….......…±0.4%
l Temperature coefficient …………........…±0.01%/℃
l Output current limiting ………….........… 120%(Typ)
l Dynamic response ……………………… 400μs
l Output current …………………………… 2-6A
l Output voltage …………………………… 5-48VDC
l Power …………………………………… 30-75W
General Characteristic
l Switching frequency …………………… 100-200 KHz
l Isolation resistance …………………… 200 MΩ
l MTBF ………………………………… >500000H
l Isolation voltage
Input-output:>1500 VAC/Min (Leakage current<5mA)
Input-case: >1500 VAC /Min (Leakage current<5mA)
Output-case: >500 VDC/Min
Main-Vice: >500 VDC/Min
l Environmental Characteristic
Case temperature …………………… Industry: -25-+85℃; Military I: -40-+85℃; Military II: -55-+85℃
Storage temperature ……………….. Industry: -45~ +105℃; Military: -55-+105℃
Models
If you can not find the required products below, pls feel free contact with us! We can supply you all kinds of power converter and switching power supply.
Remark: Custom-made specifications are acceptable.
Mechanical drawing and pin definition
