Twintex TP 2303TK High Quality Adjustale Linear Laboratory DC 30V 3A Multiple Output Power Supply
- Category: >>>
- Supplier: Twintex Electronics Co. Ltd.
Share on (60350403244):
Product Overview
Description
Twintex TP-2303TK High Quality Adjustale Linear Laboratory DC 30V 3A Multiple Output Power Supply
Product Description
Features
Two independent adjustable outputs 0-30V/0-3A×2, one fixed output 5V/3A×1
Constant voltage and constant current operations
Low ripple and noise, low temperature drift
Auto Series and Parallel tracking operations
Output ON/OFF control
Preset voltage and current
High efficiency, high power density
Over load and reverse polarity protections
Dual-color four digital panel meters
Selection guide
Model | TP-2303E TP-2305E | TP-2303C TP-2305C | TP-2303K TP-2305K | TP-2303 TP-2305 | TP-2303TK TP-2305TK | |
Output voltage | 0~30V x2 | 0~30V x2 | 0~30V x2 | 0~30V x2 | 0~30V x2 | |
Output current | 0~3A x2 0~5A x2 | 0~3A x2 0~5A x2 | 0~3A x2 0~5A x2 | 0~3A x2 0~5A x2 | 0~3A x2 0~5A x2 | |
Fixed output | 5V/3A | 5V/3A | 5V/3A | 5V/3A | ||
Preset V&I |
| √ | ||||
Output ON/OFF | √ | √ | √ | |||
Tracking operation | √ | √ | √ | √ | √ | |
Dimension (WxHxD) | 255x155x330mm | 255x155x370mm | ||||
Weight | 7kg/9kg | 7kg/9kg | 7kg/9kg | 8kg/10kg | 8kg/10kg | |
Detailed Images
Company Information
Warranty
All products by TWINTEX are tested and guaranteed to keep in good quality with one year warranty except wearing parts, such as test leads and power cords.
If quality problems happen during warranty period, we provide technical supports and spare parts. Our local distributor if any will help to solve your problems in time after receiving phone calls or emails.
Welcome to contact us at any time if any questions about using our products.
However, TWINTEX is free of responsibility to personal injuries or property damages caused by improper operation.
