4.2 CFM 53CFM Rotary Vane Vacuum Pump 380V for Vacuum Oven
- Category: >>>
- Supplier: Shanghai Yanhe Instrument Equipment Co. Ltd.
Share on (60352750382):
Product Overview
Description
Product Description
Specification
Model | 2X-2B | 2X-4B | 2X-6B |
Pumping Speed(L/S) (m3/h) | 2(7.2) | 4(14.4) | 6(21.6) |
Extrem Pressure(Pa) | ≤4*10-2 | ≤4*10-2 | ≤4*10-2 |
≤1 | ≤1 | ≤1 | |
Speed(r/min) | 1400(1700) | 1400(1700) | 1400(1700) |
Voltage | 220V/380V | 220V/380V | 220V/380V |
Motor Power | 0.37KW | 0.55KW | 0.75KW |
Inlet diameter(mm) | G3/4 | G3/4 | 30 |
Noise level(dBA) | 65 | 66 | 68 |
Oil capacity(L) | 0.8 | 0.95 | 1.-1.2 |
Exterior Dimension(mm) | 480*140*250 | 520*140*250 | 560*220*250 |
GW/NW(kg) | 22/20 | 24/22 | 45/40 |
Model | 2X-8B | 2X-15B | 2X-25B |
Pumping Speed(L/S) (m3/h) | 8(28.8) | 15(54) | 25(90) |
Extrem Pressure(Pa) | ≤4*10-2 | ≤4*10-2 | ≤4*10-2 |
≤1 | ≤1 | ≤1 | |
Speed(r/min) | 1400(1700) | 1400(1700) | 1400(1700) |
Voltage | 380V | 380V | 380V |
Motor Power | 1.5KW | 1.5KW | 2.2KW |
Inlet diameter(mm) | 40 | 40 | 50 |
Noise level(dBA) | 70 | 72 | 74 |
Oil capacity(L) | 2.3-2.5 | 2.8-3.3 | 5.5-6.5 |
Exterior Dimension(mm) | 650*240*430 | 700*240*430 | 770*240*430 |
GW/NW(kg) | 58/52 | 67/62 | 75/70 |
Packing & Delivery
Standard Corrugated Carton packing
