2 horse angle load trailer with kitchenette bunk beds inside

Product Overview

Description

2 horse angle load trailer with kitchenette bunk beds inside



1.The double hot dip galvanized chassis offers a 15~20 years guarantee against rusting in bad working condition (most factories use hot dip galvanized pipe welding. Although the steel doesn’t rust, the welding parts will. We choose the whole chassis galvanized after welding.)



2.Different ATM will need different tyres. Three horse and more will choose 205R tyres which can keep transportation much safer also conform the ADRS.



3.50*50 axles making the trailer more strong



4.17.5mm ultra thick anti-slip rupper floor



5.Water tank including the level display , Show you the detailed information .



6.protection cover for gas struts in tailgate.



7.5MTs’ gooseneck adopt gas brake.



8.Beautiful style of closed front.



9.FRP roof is much tougher.



10.Upgated U shape big horse ring is tougher and more convenient.



11.Button lock in the cupboard , practical and convenient .



12.Australian standard coded Trailer chain



13.The user instructions are provided



14. Weld axle to plate to avoid movement,both sides of axle

3mm Fiber-glass roof ,durable and sturdy

High quality window(drop-down,side and front)



Double hot dip galanized chassis with strong RHS

Double electric axles ,50*50 , making the trailer more strong and safe.

Five 185R14C tyres and 14’ aluminum alloy rims including a spare wheel

Brake-away system

Horse ring to waterproof

 All the LED Conform to ADRS

Detailed parameter

Model	STD-2HAL-L860
Materials	Chassis Material: double hot dip galvanized RHS (3.5mm-4.0mm)
	Frame Material: double hot dip galvanized RHS (2.5mm)
	Body Panel: galvanized sheet (1-1.5mm)
	Roof: Special molded FRP
Brake	Perfect security structure design, double axle electric brakes
Drawbar	Drawbar Checker Plate 1.2mm aluminium
	Drawbar Safety Chain two & Bracing Wheel one
Suspension	Roll rocker tandem spring 7 plate
Axles	Two special trailer axles 50*50
Wheels & Tyre	Five 185R14 tyres and 14' aluminum alloy rims including a spare wheel
Rubber Matting	18mm special plywood for floor& ramp door
	Rubber Matting For Inner Side Panel           6mm Rubber Matting
	Rubber Matting For Floor & Ramp Door   17.5 mm anti-slip rubber sheet
Windows& Doors	Front Window (mm) 1220*610
	Side Sash Windows   600mm*400mm*4
	Skylight   two large size upturning ventilation windows
	Rear Upper Door (mm)1980*1065 Strut & High-intensity anti-rust strut
	Ramp Door (mm) 2030*1210
	Side Door (mm)   1730*615
	Hinges for Rear Upper Door   special 6mm diameter copper hinges
Supporting Wheel	Swing-able knight supporting wheels to make parking safe and reliable
Lights& Retro Reflectors	Trailer Plug       Seven-prongs Plug
	Rear Lights brackets aluminium
	LED interior lights, two small LED sidelights, two LED combination taillights
	Retro Reflectors   8
Auxiliary Fittings	Cupboard         Front
	Horse Protection Frame fully padded
	Horse Ring       Four
	Saddle Rack   in saddle box(1200mm height for 2 saddles)
	Rug Rack         Side
	Saddle Box       One
Dimensions	Body Dimension (L x W x H: mm) : 4120 x 1980 x 2230
	Inner Dimension (L x W x H: mm) : 4070 x 1930 x 2155
	Overall Dimension(L x W x H: mm): 4970 x 2290 x 2600
	Length of Tone (mm):     850
Empty Weight	1500 KGs
Carrying capacity	1800 KGs
