CE RoHS approved 10W 24V 0.42A waterproof LED driver BG-10-24


Features





1.IP68


2.High Efficiency and good price


3.Built-in EMI filter


4.100% full load burn-in test


5.Low output ripple and noise
6.Protection:Over load/Over voltage/Short circuit


7.LIFETIME WARRANTY





Specifications









































































































ModelBG-10-12BG-10-24
DC  voltage12V24V
Rated current1.25A0.42A
Ripple and noise100mVp-p100mVp-p
Intet stability±0.5%±0.5%
Load stability±1%±0.5%
Efficiency81%83%
voltage ADJ. range12V±10%24V±10%
AC voltage range90~264VAC 47~63Hz; 250~370VDC
AC Inrush currentCold-start current 30A/250V
Overload105%~150% Type:pulsing hiccup shutdown Resete:auto recovery
Over voltage121%~142% Rated output voltage
Short circuitHiccup mode, recovers automatically after fault condition is removed
Setup,rise,hold up time100ms 60ms /230VAC at full load
Withstand voltageInput and output internal:1.5KvAc,input and enclosure:1.5KvAc,Output and enclosure:0.5KvAc
Isolation resistanceInput and output internal:Input and enclosure,Output and enclosure:500VDC/100MΩ
Working temperature and humidity-10°C ~+50°C
Store temperature and humidity-20~+85°C, 10~95%RH
Overall dimension116×29×20mm 126PCS/CARTON
Weight0.12KG
CE EMC AuthenticateEN55022:2010 EN61000-3-2:2006+AL:2009 EN61000-3-3:2008
EN55024:2010 EN55015:2006+AL2007+2009 EN61547:2009
CE LVD AuthenticateEN61347-1:2008T A1:2001 EN61347-2-13:2006
EN60950-1:2006+A11:2009+A1:2010+A12:2001
ROHS AuthenticateEPA3050B:1996 EN1122B:2001 EPA3052:1996 EPA3060A:1996
EPA7196A:1992 EPA3540C:1996 EPA8270D:2007 IEC62321:2008





678





Packaging & Shipping


9





Our Services


We are the only supplier in Alibaba can provide LIFETIME WARRANTY power supply,please don't be hesitate to check with our Ali web://wodecn.en.alibaba.com/   and contact us by TradeManager or Skype for more details(our TM ID is wodecn and Skype ID is wode.smps).
