Product Overview

Description

chargable gps vehicle tracker TK102 Real time tracking can remotely power cut off device with removable battery sos button





Specification



Enclosure dimensions	93mm*62mm*25mm
Weight	200g
DC Tolerance voltage	9V - 35V
GSM Module	850/900/1800/1900MHz
GPS Module	MTK
Protocol	NMEA0183
Number of Channels	Hundreds of Channel Simultaneous Operation
Current (GPRS online)	60mA
Current (GPRS transmission)	80mA
Sleeping mode	40mA
Accuracy Horizontal	<5 meters (50%), <8 meters (90%)
Altitude	<10 meters (50%), <16 meters (90%)
Velocity	0.06 m/sec.
Hot Start:	<13 sec
Warm Start:	<42 sec
Cold Start:	<84 sec
Backup battery	800mAh
Communication	GPRS \\SMS\\RS232
Operating Temperature	-40°C to +55°C
Storage Temperature	-40°C to +65°C



Features



• History route playback


• lifetime free platform


• Hidden gps tracker


• Real time tracking


• Accurate position


• Geo-fence


• Global location


• Built-in back up battery


• Viarous Reports supported


• SMS / GPRS / Internet data transmission



Functions



1.Report:

• Intelligent report


• Fixed time/distance report


• Direction change report


• Over speed report


• Report simple (very easy compatible with your software)

2.Alarm:

• SOS alarm


• Lower battery alarm


• Arming and disarming


• Emergency release

3.Other:

• Geo-fence


• Parameter configuration (via sms or pc-setup setup it)


• Support Tcp/udp communications


• Built in memory, storage the data in no gsm signal place.


• Odometer or mileage(Via gps calculates mileage)


• Prevent static excursion.


• ACK check enable or disable


• SMS function


• Built in backup battery, Lower battery alarm/power cut alarm


• Remote fuel cut off


• Sleeping mode


• Remote Door Lock/unlock control


• Panic



• Anti-car jacking


4. Options:

• Temperature sensor


• Fuel sensor


• Odometer sensor (Via odometer pulse get odometer)


• silk-screen logo



Physical Display







Applications



• Vehicle tracking


• Truck  tracking


• Fleet managemen



Best mounting places



Installation Diagram













Optional accessories



• Temperature sensor


• Fuel cable


• Fuel sensor



 Deliver within 2-7 days after confirmed payment. You could choose the Courier!







TrackckPro Industrial Co., Ltd., which founded in 2000, is a high-tech enterprise specialized in customized GPS series device, including GPS tracker/GPS tracking system, Vehicle alarm system, GPS tracker covert. We pay attention to manufacture and marketing both domestically and overseas. Our business guideline strives for 100% customers' satisfaction through continuous improvement of working methods and processes. Our mission remains to develop tiptop products with the reasonable prices while defining industry standards for quality, reliability and innovation.

Factory Display



Locating on web-based gps tracking software







Android/IOS app also supported







Q: Why the tracker can't be switched on?

A: 1. Check if wiring is correct or not.

    2. Charge the tracker.



Q: No response to SMS command

A: 1. Wrong password. Please check your password.

    2. No GSM mobile signal or weak GSM network. Try later.

    3. Out of SIM credit. Please pop up.

    4. SIM is damaged. Change a sim card.

    5. SIM card is without sending function. Change a SIM or enable SMS sending function and caller identification function.

    6. SIM card isn't installed properly.



 Q: Is there a monthly charge for it to communicate with me. Does it require a cellulare service provider or something else?

A: Two communication ways: SMS ( just like one mobile phone to another) and GPRS ( monitor/manage the tracker on our tracking platform) . These two ways are both charged by your local telecom carrier, we don't charge for the SMS or GPRS fee.



Note:

1. you can just choose one or both two of the two way communications to get the real time location info and so on from the tracker : SMS or GPRS or both )

2. No matter via SMS or GPRS communication, there is one simcard(the one has gprs function and caller identification function, you'd better buy from the local telecom carrier) needed to be inserted in the tracker. NO data plan required by us.

Certificates







Click on image to konw the product more detailed information







My skype: trackpro09
