one part bonding and sealing neutral silicone sealant for solar pv junction box
- Category: >>>
- Supplier: Guangdong Haoming Organic Silicon Material Co. Ltd.
Share on (60356903034):
Product Overview
Description
one part bonding and sealing neutral silicone sealant for solar pv junction box
APPLICATIONS
- Use for Bonding, Fixed, insulation, sealing circuit board ,electronic components
- Wide range of applications on bonding, sealing and insulation for Electronic, electrical parts
- Absorb shake and shock, for the support of parts
- Widely used on bonding and sealing for electrical appliances which need to be high temperature resistance situation.
Product description
1.Single component dealcoholization neutral curing, non-toxic, Non-corrosive effect for the materials, simple operation process.
2. Good adhesion and high bonding strength for all kinds of plastic, metal, glass and other materials.
3.Superior electric insulation performance
4.High and low temperature resistance performance advantages,can be long-term use in the temperature range:-45℃~+180℃
5.Good water resistance, moisture resistance, waterproof performance
Parameter
Color: | White/Black | Viscosity | Micro flow |
Specific gravity(g/cm3) | 1.15g/cm³ | Hardness(HSA) | 30±3 |
Strength of extension(MPa) | ≥1.0 | Shear strength (Mpa) | ≥1.0 |
Elongation at break | 260% | Using temperature range ( ℃ ) | –45 +180 |
Breakdown voltage KV/mm | 14 | Volume resistivity Ω.cm | 5*1014 |
Permittivity | 2.80 | Face dry time (min) | 15(25℃,50% RH) |
Usage
Product Package
PACKING
Plastic bottle ,300ml/pc
Storage
Store in a cool, dry place at -20℃~27℃.storage life:6 months after the date of manufacture.
Attention
This product is completely cured and non-toxic, but should avoid contact with the eyes and the child before curing, keeping the working environment ventilate. At the same time, due to the diversity of the application environment, the application conditions are not under our control, in order to ensure that our products can meet your requirements,customers should do the experiment before use the product.
FAQ
1. What are the normal package ?
100 ml /300 ml /2600 ml /18.9 L for one part silicone sealant
1 kg /tin for heat sink compound
20 kg / barrel for two parts potting compound
2. Normal application temperature ?
Normally it's -50C - +180C ,depends on specific item .
3. Does your silicone sealant corrode metal and plastic ?
No, it doesn't .All of our silicone sealant are neutral .
4. What kind of silicone sealant are you selling ?
We are selling neutral silicone sealant for LED ,automobile ,Solar PV ,consumer electronics ,craft ,etc
5. Are your silicone sealant Eco-friendly ?
All of our silicone sealants are Eco-friendly ,they have gone through RoHS, REACH tests every year .Some have UL certificates .
6.What is the Shelf life of your silicone sealant
When stay unopened, shelf life is six months from the date of manufacture, keep in cool and dry place (-20℃~27℃).
Advantages
1. We have been in silicone sealant industry for more than 10 years
2. We have supplied our silicone sealant to many famous brands in and out of China ,which include Philips India ,Videocon ,Midea ,Galanz ,Nationstar ,FOXCONN ,etc .
3.Haoming provide comprehensive range of electronic silicone sealant ,which are widly used in LED ,Solar PV ,automobile ,consumer electronics ,etc .
4. We have a professional R&D team ,products have stable quality .
