BSH-SP9100A auto painting oven/thermal car paint booth/used car painting booth
Product Description
♥ Tips:We also can produce the machine as your requirments.
Dimensions:
Length(mm)
Width(mm)
Height(mm)
Outer Size
8,000
4,000
4,200
Internal Size
6,900
3,900
2,650
Entrance Door
Adopt with handle and lock
3,000
2,600
Operatior’s Door
Adopt with handle and Anti-Explosion
800
2,000
Spray Booth Configuration:
Features:
Total power 30 kw; 380V/3ph/50hz; Noise < 80db
I. Wallboard & Roof board
Adopt high quality EPS panel, thickness: 50mm, socket type assembling.
Ramps×2pcs, 630 mm with slope. Roof board with 0.7mm zinc plated
steel sheet, single layer.
II. Foundation System
All around with welded 1.2mm zinc plated steel sheet, Bearing bracket
with welded zinc plated steel is full of hot dip galvanized steel. Two rows
of grid and three rows of diamond plate.
III. Heating System
Adopt surface type infrared heat lamp,10 group×3pcs, 1kw/pc.
IV. Filtration System
Inlet with high grad fiberglass filter, which filtered the dust larger than
10um, roof with EU5 CC-600G filter, TSP value: ≤1.4mg/m3.
V. Light System
With Philips lamps and electronic ballast, with 45 degree installation at
inner side of roof, it can still work under 180v.
VI. Ventilation System
Adopt two pcs energy saving fan, power 1.5kw, Air volume: 24000m3/h;
Rated air speed: 0.3m/s, air changes; 260 times/h. With 3 pcs straight
air ducts, 1pc ellow airduct.
VII. Control Panel
One unit, including lighting switch, painting switch, warm painting, baking
temperature,time setting, urgent stop switch. All components with
famous domestic brand .
VIII. Other Include
All sets of hardware, fasteners and sealants
Customer Feedback
Packaging & Shipping
Our Services
1. OEM ODM service.
2. Customized service: The color and size of the product can be customized.
3. One Year Quality warrant service, during the period spare part supplied free if you pay for shipping.
4.Professional team supply service for life long time.
Company Information
Shandong Lantian Huaer Environmental Protection Equipment Co.,Ltdis professional auto maintenance equipment manufacture since 2000with brand “BLUESKY”, in Chinese Lantian means Bluesky.
Our factory covers an area of more than 2,500 squares metters and with our up-today manufacturing facilities, high tech industrial, product developing manufacturing sales and perfect after-service with total capital of more than ten millions.
For many years our copany have been awarded as”Enterprise with high reputation” ”Enterpris with high credit in quality” and “China national grade AAA enterprise” ....etc. Besides, we have passed ISO9001, authenticated by 2000 international quality control system.
Customer Visit
FAQ
1. Can you make the machine size and color as our request?
Yes, we can make the machine size and color according to your request.
2. What’s the Min order to your company?
1 set.The sample order, if we have stocks, we will send out the products within 1 week.
3. OEM is available?
Yes, we can put your logo on the machine if needed.And we can make the machine structure as your design request.
4. What kind of measuring system do you have?
We have the two dimension measuring,three dimension measuring and CHEIF electric measusing system for your choice.
5.What’s the advantage of your company?
We have exported our lifts and service to more than 100 countries. We have specialized team work for you, you will get our feedback within 24 hours./ Germany and Italian advancedtechnology.
Contact
Good cooperation comes from good communication.
If you have any question, please freely to contact me.
