Multilayer PCB Circuit Board and Induction Stove PCB Board
We welcome custom order , with one-stop service .
1. We can help you for PCB fabrication .
2. If you do not have SMT line , we can help you finish the PCB Assembly process .
3. We can help you to purchase the components .
Our Capability
Materials can choose | FR-4 , CEM-1, CEM-3, Aluminum Base , Rogers , High TG and other |
Layer | 1-40 Layers |
Panel Size | Min. size : 0.25*0.25 inches(6*6mm) Max. size : 1200*600mm |
Board Thickness | 0.6 - 6.0 mm |
Thickness tolerance | ± 10% |
Copper Thickness | 1oz , 2oz, 3oz, 4oz, 5oz |
Copper thickness tolerance | ± 0.25oz |
Min. Via Diameter | 0.075mm (3 mil) with laser drilling , 0.2mm(8mil) with CNC drilling |
Min. Line Spacing | 0.075mm |
Min. Line Width | 0.2mm |
Solder mask | White Black Green Blue Red Purple and other colors |
Silk screen | White , Black etc |
PCB cutting | Routing and V-cut |
Files needed | PCB : Gerber files(CAM, PCB, PCBDOC) Components : Bill of Materials(BOM list) Assembly : Pick-N-Place file |
We can help you customize PCBs suitable for different purposes .
Single layer PCB | for simple electronic device with relatively few functions , for example , PCB in mouse or for simple toys | ||||||
Multilayer PCB | Used in electronic products with complex circuit and many functions, for example PCB in laptop , mobile phone , medical equipment etc | ||||||
Aluminum Base PCB | used in electronic products which requiring good heat dissipation , for example LED lights | ||||||
HDI PCB | used in electronic products with more compact design and stronger signal processing capabilities, which can meet multiple functions such as high-frequency communication, data transmission, and image processing. for example Motherboard , GPU, Mobile phone etc | ||||||
Heavy Copper PCB | Applied to electronic products requiring higher current , higher power and higher heat dissipation . for example Power Module , Inverter and Frequency converter . | ||||||
High Frequency PCB | With high electromagnetic frequency meets the requirements of high-speed signal transmission, low noise and high precision. for example Automobile anti-collision system , radio system . | ||||||
Edge Plating PCB | Applied to device control board that require good EMC control radiation and anti-interference ability, for example microwave or RF products . | ||||||
Flexible PCB | or FPC . Light weight, thin thickness, and can be bent and folded freely . used in small but precision electronic equipment. for example UAV , mobile phone , sensor and others . | ||||||
Application Field
PCB Board we have produced are mainly used in the Industrial Control, Medical Treatment, Automobile area. All the products must meet ISO9001 UL etc. certification with high quality sodering for wires and no fingerprint.
