Product Overview
Description
Product Dispaly
Item NO : T-13
==Product Features==
1.Providing super-large space for operation, more suitable for medium and or large-size tents, vehicle hoods, inflatable boat, hoods, and fire boat, etc.
2.Controlled by programmable PLC, displays the digital setting by high clear display processes
to be modified at any time according to user’s requirement.
3.Auto controllable temperature, highly stability, temperature very between ±2°C, the upperlimit temperature with alarming device.
4.To design controlling by feet at ease, suitable for long working according to physical Dynam.
5.Be possible of working 24hours continuously and produce highly efficiently.
6.Unique heating tube structure design.
7.Auto slightly fading function, to avoiding blank space of hot air sealing.
8.Providing with king-size of twist square design.
==Product Application==
The machine is applicable of waterproof or leakage prevention and rubber material such as PVC, PU,
rubber and three-ply cloth. It is applicable to manufacturers for waterproof prevention equipment such as tents,
waterproof bags, car cover, shipping cover and military waterproof cover, ect.
==Technical parameter==
Model | T-13 |
Power supply | AC 220 V50Hz |
Rating efficiency | 3000W |
Heat control | temperature~700°C adjustable without bands |
Speed | Standard:1~18m/min infinitey variable. |
Air supply | 0.35~0.5 Mpa |
Pinch roller width | Standard:30mm mill finish, steed grain straight grain to be chosen according to demand |
Width of the gun diameter | Standard:24mm or 27mm, others can be choosen according to demand |
Exterior size | 1790mm(L) X 720mm(W)X1600mm(H) |
Net weight | 245kg |
Prevention against jumping over sewing work | There are adjustable devices to prevent the gun from jumping over the seamed sections when the gun is moving inward with the idle wheel starting, or when the gun moving outward with the idle wheel stopping |
Our Machine
Operation Panel with both Languages (Chinese & English) for Options
Accessories
Our Services
Warranty Period
First half year warranty will be provided for all electrical element of new sold machines one year
warranty for all mechanical parts (under warranty free replacement parts are available),Our machines are modular
design that can repair by swapping module (free spare parts will be provided for not-consumable parts, e.g. roller, or not caused by improper use, when under warranty period).
Maintenance
All machines must be placed indoor, and cannot be under high temperature working environment.
Air-conditioned set up would be favored.
Initial Machine Startup Installation
All machines are in good testing before delivery,once you got the machine,only connect the air
compressor and choose language in English. Then you can set up speed and temp. according to your requirement.( Details refer to the instruction)
Machine Repairing
We can offering the online videos technology support service for machine repairing .
Technology Support
For any technical problem, we will discuss with customers to investigate their problem and finding
solution.
We can quote lowest prices separately for spare parts and freight
Packaging & Shipping
Plywood Packaging for Export Standard
