UTV 600cc Motorcycle Engine for Sales
- Category: >>>
- Supplier: Chongqing Longdo Technology Co. Ltd.
Share on (60360368069):
Product Overview
Description
UTV 600cc Motorcycle Engine for Sales
Product Description
| Engine Model | 188MR | 196MS | 196MT |
| Engine Name | ATV500 | ATV600 | ATV650 |
| Engine Type | Single Cylinder,4 Stroke, OHV,4Valve, Water/Oil Cooled,Vertical | ||
| Displacement(ml) | 493 | 594 | 622 |
| Dimension(mm) | 625*600*475 | ||
| N.W(kg) | 74 | ||
| Max Power(kw/rpm) | 25/5250 | 27/5250 | 29/5250 |
| Max Torque(N.m/rpm) | 48/4250 | 55/4250 | 57/4250 |
| Compression Ratio | 10.3:1 | 10:01 | 10.3:1 |
| Bore*Stroke(mm) | 87.5*82 | 96*82 | 96*86 |
| Ignition Type | EFI/CDI | ||
| Lubrication Type | Pressure Splash | ||
| Min. Fuel Consumption (g/Kw.h) | <354 | ||
| Starting Type | Electric/Kick Start | ||
| Carburetor | BSR36-126(150#) | BSR36-126(155#) | BSR36-126(160#) |
| Clutch | Wet Multi Plate Oil Bath Type Clutch | ||
| Gear Shift | CVT+Manual Gear Shift | ||
