jacquard Socks Machine (plain and terry) 4.5 inch Socks Making Machine Quality

Product Overview

Description

The full computer   jacquard Socks Machine can make  socks like rabbit hair, sheep woolen and other material made scoks Three-dimension.





Mode	WY-6FBP(plain)	WY-6FBR( plain$terry)
Cylinder diameter	4 inch	4 inch
Needles	64N~240N	64N~176N
Rotational speed	300~330RPM	220~260RPM
Drive motor power	1.0KW	1.0KW
Control box	0.2KW	0.2KW
Electricity	0.55-0.6 MPa	0.55-0.6 MPa
Electricity	220V/380V	220V/380V
Floor space	150*95*220CM	150*95*220CM
Blower power	0.35 KW	0.35 KW
packing	Packed with bakelite plate 165*95*85 cm 1.5CBM NW:300kg GW:330kg	Packed with bakelite plate 165*95*85 cm 1.5 CBM NW:300kg GW:330kg
Throughput(pairs/24 hours)	men’s sock : 280 women’sock: 300 children’s sock :360 stocking : 150	men’s sock : 210 women’sock:250 children’s sock :310 stocking : 120



Main features:

1.One main feeder plus five pattern feeders

2.Possibility of 6 colors in one course and 16 colors on one sock.

3.Drumless, fully computerized control system.

4.Exclusive inner cam block system for high speed.

5.Stepping motor for elastic yarn and stitch cam control.

6.Electro-pneumatic yarn finger and cam control.

7.Pattern Depth up to 1,500 courses.

8.Multiple stop motion sensors in case of error.

9.Autiomatic re-cycling oiler,counter,and reset function.

10.Equipped with USB for easier data reading

11.Available in 220/380/440V 3phase 50/60Hz.

12.Fully A.C Servo motor adopted.

13.Minimized and easy operating function.

14.battery back-up to protect stored program.

15.Internal UPS can support continuous knittin

16.Graphic type LCD adopted
