Blown film machine/polyethylene plastic film blowing machine price/plastic bag production line
- Category: >>>
- Supplier: Laizhou Liangong Machinery Co. Ltd.
Share on (60366507838):
Product Overview
Description
Blown film machine/polyethylene plastic film blowing machine price/plastic bag production line
1,Plastic film blowing machine
The plastic film blowing machine is used for blowing the LDPE,LLDPE,HDPE films. Which is used for making vest bags and flat
pockets.
Raw material: LDPE,LLDPE,HDPE grains.
Model: LGSJ-50FM-700
Screw diameter: 50mm
Film folding diameter:100-650mm(Film width)
Single film thickness: 0.08-0.2mm
Maximum yield: 40 kg / h
aspect ratio: 28:1
Host Power: 11kw
Traction motor power:1.1kw
Dimension(L×W×H): 3.2m×4m×1.6m
2, Hot sealing cold cutting bag making machine
The machine could cut and seal the plastic film, it is suitable for making vest bags, flat pocket.
Raw materials: PP, PE Double-layer film.
Model: 600
Max Bag-making Width : 30-550 mm
Max Bag-making Length: 800mm
Bag-making speed: 30-150 pc/min
Power of motor: 1.1kw
Machine Weight: 750 kg
Dimension(L×W×H):2.9m×1.35m×1.65m
3, Plastic film printing machine
This printing machine is used to print plastic bags, plastic film, single-double-side printing will be finished in one time.
Raw material: plastic film or plastic bags.
Model: 600
Printing colors: two
Printing width:600 (mm)
Printing length:200-1250 (mm)
Max. printing speed: 10-60 (m/min)
Register precision:0.15 (mm)
Moter power:4 (kw)
4, Punching machine
It is used to punching the shape of the T-shirt bag, hole bag, You can punch all kinds of design of the bag by changing the
punching knife.
Raw materials: plastic bags, plastic film.
Model: 5T
Moter power: 1.1kw
Machine weight: 5T
Platen Stroke: 28mm
Platen distance :150-215mm
Machine Weight: 500kg
Dimension (L×W×H):1.2x0.8x1.2m
Okiguchi size :400-500mm
1,Plastic film blowing machine
The plastic film blowing machine is used for blowing the LDPE,LLDPE,HDPE films. Which is used for making vest bags and flat
pockets.
Raw material: LDPE,LLDPE,HDPE grains.
Model: LGSJ-50FM-700
Screw diameter: 50mm
Film folding diameter:100-650mm(Film width)
Single film thickness: 0.08-0.2mm
Maximum yield: 40 kg / h
aspect ratio: 28:1
Host Power: 11kw
Traction motor power:1.1kw
Dimension(L×W×H): 3.2m×4m×1.6m
2, Hot sealing cold cutting bag making machine
The machine could cut and seal the plastic film, it is suitable for making vest bags, flat pocket.
Raw materials: PP, PE Double-layer film.
Model: 600
Max Bag-making Width : 30-550 mm
Max Bag-making Length: 800mm
Bag-making speed: 30-150 pc/min
Power of motor: 1.1kw
Machine Weight: 750 kg
Dimension(L×W×H):2.9m×1.35m×1.65m
3, Plastic film printing machine
This printing machine is used to print plastic bags, plastic film, single-double-side printing will be finished in one time.
Raw material: plastic film or plastic bags.
Model: 600
Printing colors: two
Printing width:600 (mm)
Printing length:200-1250 (mm)
Max. printing speed: 10-60 (m/min)
Register precision:0.15 (mm)
Moter power:4 (kw)
4, Punching machine
It is used to punching the shape of the T-shirt bag, hole bag, You can punch all kinds of design of the bag by changing the
punching knife.
Raw materials: plastic bags, plastic film.
Model: 5T
Moter power: 1.1kw
Machine weight: 5T
Platen Stroke: 28mm
Platen distance :150-215mm
Machine Weight: 500kg
Dimension (L×W×H):1.2x0.8x1.2m
Okiguchi size :400-500mm
Product Description
Specification
item | value |
Application | Film, bag |
Plastic Processed | PE, PP |
Condition | New |
Screw Design | Single-screw |
Screw diameter (mm) | 50 mm |
Screw L/D Ratio | 28:1 |
Screw Speed (rpm) | 60rpm |
Showroom Location | None |
Place of Origin | China |
Shandong | |
Brand Name | Liangong |
Voltage | 380V |
Dimension(L*W*H) | 6m*1.6m*2.5m |
Weight | 4T |
Certification | CE/BV/SGS |
Warranty | 1 Year |
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support | |
Key Selling Points | Competitive Price |
After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service |
Local Service Location | None |
Applicable Industries | Manufacturing Plant, Other |
Marketing Type | Hot Product 2019 |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Warranty of core components | 1 Year |
Core Components | Motor |
After-sales Service Provided | Engineers available to service machinery overseas |
Usage | Making t-shirt bag |
Product Type | Pe Film |
Processing Type | Exturding Machine |
Product | Stretch Film |
Type | Film Extrusion |
Material | PP PE LDPE HDPE |
Inverter | ABB Brand |
Automatic Grade | full automatic |
Power | 30KW |
Company Profile
Established in 1992, Laizhou Liangong Machinery Co., Ltd. (former Laizhou city Shahe plastic machinery factory) is a professional plastic machine manufacturer. Located in Shahe Town of Laizhou City, enjoying convenient transportation and graceful environment, near Laizhou Bay at the junction of Yantai, Weifang and Qingdao.
Our company has precise machining capacity and superior technicians with many years of experience in design and manufacture, advanced production equipment, perfect management system. From the beginning, we keep: market is the guider, technology is the supporter, make excellence, seek specialty. At present our company is the leading enterprise in domestic plastic machinery field, specialized in manufacturing and selling plastic machinery: plastic recycling granulator series, plastic packing machinery, plastic pipe making machinery, plastic foaming machinery, plastic board, strip, sheet and mat etc series plastic machinery and auxiliary equipments etc. which features advanced technique, high degree of automation, high efficiency, energy-saving and so on. Now our products have been sold to everywhere in domestic, and also exported to Europe, Africa, Southeast Asia and Taiwan etc. more than 50 countries and regions, won the client's trust and support from domestic and overseas.
We look forward to establish business relationship with you! We warmly welcome you to visit our factory and cooperate with us!
Our company has precise machining capacity and superior technicians with many years of experience in design and manufacture, advanced production equipment, perfect management system. From the beginning, we keep: market is the guider, technology is the supporter, make excellence, seek specialty. At present our company is the leading enterprise in domestic plastic machinery field, specialized in manufacturing and selling plastic machinery: plastic recycling granulator series, plastic packing machinery, plastic pipe making machinery, plastic foaming machinery, plastic board, strip, sheet and mat etc series plastic machinery and auxiliary equipments etc. which features advanced technique, high degree of automation, high efficiency, energy-saving and so on. Now our products have been sold to everywhere in domestic, and also exported to Europe, Africa, Southeast Asia and Taiwan etc. more than 50 countries and regions, won the client's trust and support from domestic and overseas.
We look forward to establish business relationship with you! We warmly welcome you to visit our factory and cooperate with us!
FAQ
1. who are we?
We are based in Shandong, China, start from 2009,sell to Domestic Market(50.00%),Africa(8.00%),Eastern Europe(8.00%),Mid East(6.00%),Eastern Asia(6.00%),Southeast Asia(6.00%),South America(3.00%),South Asia(3.00%),Western Europe(3.00%),Oceania(3.00%),Northern Europe(2.00%),Central America(2.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Plastic Machinery (Plastic Recycling Granulator/Plastic Packaging Machine/Plastic Pipe Making Machine/Plastic Foaming Machinery/Plastic Rope Machinery/Plastic Mat Machinery),Plastic Products,Chemical machinery,Construction machinery,Technology Import and Export
4. why should you buy from us not from other suppliers?
Laizhou Liangong Machinery Co.,Ltd. is professional plastic machine manufacturer. Our factory was founded in 1992, had Twenty years plastic machine manufacturing and exporting experiences. The products are well sold to many regions throughout the world.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF；
Accepted Payment Currency:USD,EUR,JPY,GBP,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Japanese,German,Arabic,French,Russian,Korean
We are based in Shandong, China, start from 2009,sell to Domestic Market(50.00%),Africa(8.00%),Eastern Europe(8.00%),Mid East(6.00%),Eastern Asia(6.00%),Southeast Asia(6.00%),South America(3.00%),South Asia(3.00%),Western Europe(3.00%),Oceania(3.00%),Northern Europe(2.00%),Central America(2.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Plastic Machinery (Plastic Recycling Granulator/Plastic Packaging Machine/Plastic Pipe Making Machine/Plastic Foaming Machinery/Plastic Rope Machinery/Plastic Mat Machinery),Plastic Products,Chemical machinery,Construction machinery,Technology Import and Export
4. why should you buy from us not from other suppliers?
Laizhou Liangong Machinery Co.,Ltd. is professional plastic machine manufacturer. Our factory was founded in 1992, had Twenty years plastic machine manufacturing and exporting experiences. The products are well sold to many regions throughout the world.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF；
Accepted Payment Currency:USD,EUR,JPY,GBP,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Japanese,German,Arabic,French,Russian,Korean
