4000l water tank truck, 4000 liters small water tank truck for sale

Main specification

Product model and name

SZD5071GSS4 watering truck

Gross weight(Kg)

7300

Drive type

4X2,RHD,LHD

Curb weight(Kg)

3205

Overall dimension(mm)

5990X1980X2380

Approach/departure angle(°)

19/15

Cab seats

3,2

Axle No.

2

Front/rear hang(mm)

1032/1658

Axle load(Kg)

2920/4380

Wheelbase(mm)

3300

Max speed(Km/h)

95

Chassis specification

Chassis model

EQ1060

Manufacturer

Dongfeng Motor Co., Ltd

Brand name

Dongfeng

Dimension(mm)

5845×1900×2220

Tire specification

7.00-16

Tire No.

6+1(One spare tire)

Steel spring number

8/9+5,6/8+4,6/6+5

Front track base(mm)

1506,1404,1500

Fuel type

Diesel

Rear track base(mm)

1466,1458,1520

Emission standard

Euro 3

Transmission

5 forward gear

Cab

Singal row,2 person allowed,Optional to add power steering,A/C

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

CY4102

Dongfeng Cummins Engine Co.,Ltd

3856

70(95HP)

Tank body

Tank capacity(m³)

5

Tank material

QB235 Carbon steel

Water pump model

65QZ40/45(Weilong pump)

Water pump flow(m³/h)

40

Watering width(M)

≥14

Water cannon range (M)

≥28

Main feature

1).Equipped with high power self-suction water pump that characterized by high-pressure and fast speed suction.

2).Equipped with front, rear and side sprinklers and high position sprinkler, and rear working platform.

3).The water cannon which is installed on the working platform can rotate by 360 degree and the water flow can be adjusted into various rain shape. There are straight shape, heavy rain, moderate rain and drizzle etc. The max range can reach 30M.

4).Equipped with fire coupling, flow valves, filter screen and water level gauge.

5).According to customers’ request, the crane, high working platform and spraying machine also can be equipped.
