number coding machine numbering and perforating machine number machine

Model

DM-P

Advanced capacities

Up to 3 lines of code with speeds up to  533ft/min.(162m/min)

Standard USB with logo and memory  back up features

Simple to maintain

6,000-hour core lifer No mess, no waste, no mistake fluid cartridge delivery system

Superior environmental protection

IP55 wash down protection standard

Console Dimensions

Stainless steel

21.3″(541mm)high   13.6″(345mm)wide   11.2″(285mm)deep

Environmental Protection

IP55

Print head

Heated print head

Diameter:1.63″(41.3mm)  Length: 9.47″(240.5mm)

Print head Umbilical

Ultra flexible

Length:6.56″(2m)   Diameter: 0.91″(23mm)

Bend radius: 3.00″(76.2mm)

Fluids Containers

Ink Smarty Cartridge 0.793qt.(750ml)

Make-up Smart Cartridge0.793qt.(750ml)

Line Speed Capacities

Can print 1 to 3 lines of print at speeds of up to 533ft/min.(162.5m/min)

(10characters per inch, single line of print)

Front Matrix Configuration

Single-line: 5×5,5×7,7×9,11×16,17×24

Twin-line: 5×5,5×7,7×9

Tri-line: 5×5,5×7

Nominal Character Height

Selectable from 0.079″(2mm)to 0.279″(8.5mm),depending on font

Throw Distance

Optimal: 0.472″(12mm)

Range: 0.197″(5mm)to 0.591″(15mm)

Keyboard

Membrane style with tactile feedback, including 72 numeric,alphabetic, and special function keys, PC-style layout to approximate international PC convention

Electrical Requirements

Nominal supply power 100-120/200-240AVC  50/60Hz.,120W

Approximate Weight

Unpacked and dry: 39.68lbs (18kg)

Temperature/Humidity Range

41°Fto 113 °F(5°Cto45°C)

0% to 90% RH non-condensing

Display

320×240 Bright blue backlit 5.7″LCD display

WYSIWYG onscreen message editing

Data Interface

Standard USB with logo and memory backup features

Message Storage

100 complex message, Unlimited storage using USB
