Very high capacity 1.2V 9000mAh nimh battery D size nimh rechargeable battery
Product Description
Battery details
ITEM
SPECIFICATION
Name
Nimh d size rechargeable battery
Cell
Nimh d
Nominal Capacity
9000mAh(0.2C)
Charging Voltage
1.4V(Std.)
Nominal Voltage
1.2V
Charging Current
Standard Charge:4A(Recomendation)
Rapid Charge:8A
Charging Method
CC-CV
(Constant Voltage with limited current)
Standard Charging Time
Standard charge:3.0hours
Rapid charge:2.5hous
Max. Charge Current
8A(ambient temperature 25 °C )
Max.Discharge Current
16A(ambent temperature 25 °C )
Discharge Cut-off Voltage
0.9V
Cell Weight
150g max.
PCB protection trip Current
8A(approx.)
Cell Dimension
Height:51.0mm Max.
Diameter:32.4mm Max.
Operating Temperature
(Ambient)
Charge:0 to 60 °C
Discharge:-20 to 55 °C
Cell surface temperature when discharging:Max 75 °C
Application:
Cellular phones, camcorders, emergency backup lighting, power tools, laptops, electric vehicles, portable medical devices etc.
Package
Our Company
Our Company
Certifications
MSDS & UN38.3
CE & UL
Cautions:
(1)Reverse charging is not acceptable.
(2)Charge before use. The cells/batteries are delivered in an uncharged state. (3)Do not charge/discharge with more than our specified current. (4)Do not short circuit the cell/battery Permanent damage to the cell/battery may result. (5)Do not incinerate or mutilate the cell/battery. (6)Do not solder directly to the cell/battery. (7)the life expectancy may be reduced if the cell/battery is subjected adverse conditions like: extreme temperature, deep cycling, excessive overcharge/ over-discharge. (8)store the cell/battery uncharged in a cool dry place. Always discharge batteries before bulk storage or shipment
Why ACT?
1. 10+ Years of experience in battery industry with extensive knowledge.
2. An own property industrail zone of 33,325 square meters.
3. More than 200 workers of production, make sure large order process.
