ZH CH2810 generator battery charger HIGH QUALITY

Category: Generator Parts & Accessories >>>
Supplier: FUJIAN,KAIYUE,ELECTRONICS,CO.,LTD

Price:$20.00 - $23.00

Price in USD:Details

Quantity:

Product Overview

Description

ZH-CH2810 generator battery charger HIGH QUALITY

General features

Intelligent Charger is specially designed for starting or working of storage battery (especially suited for full-sealed solid wide-temperature storage battery) in diesel engine. It is a intelligent mode of switch structure. It features in constant pressure, constant current, tricking current, resistance of short circuit, and fully automated function.

Data Sheet.1

Power Input	Voltage 160~165VAC Frequency 20~100Hz Current:10A ±0.1
DC Output	Voltage 13.8 VDC, Current 5A--when battery group=12V Voltage 27.6 VDC, Current 3A--when battery group=24V
Charge Mode	Float charge
DC Voltage Regulation	< ±1%
Efficiency	> 85% @ Full load
Contact Capacity	0.5A @ 120 VAC
Protection	Reverse polarity, over-voltage, short circuit, current limiting
Environment	Operating Temperature : -20~50 °C Storage Temperature : -30~85 °C Relative Humidity : Maximum 90% Vibration : 1.5G @ 5~30 Hz / 5.0G @ 30~500 Hz
Dimensions	180(L) x 160(W) x 60 (H) mm
Weight	0.67 Kg
