Hot sale High Quality packaging materials film/paper/foil/fabric roll slitting machine

Product Overview

Description

High Quality slitting machines for sale Mini slitting machine Slitting Machine

1. This paper slitter rewinder machine is suitable for slitting big jumbo roll of adhesive label paper, craft paper etc.


2. It adopts PLC with touch screen for convenient operation.


3. Unwind part uses Pneumatic brake, and PLC calculates the diameters automatically to achieve constant tension.


4. Rewind part is driven by vector motor, constant liner speed.


5. rewind part uses hydraulic lifter to lift rewind rolls.


6. Hydraulic auto loader is used for unwind mother roll, and auto unloader in rewind roll, it save human cost and time.


7. EPC system is used in this machine, the photocell and hydraulic webguide are for optional.


8. This system has advantages of Start Buffer, Stop without loose; Meter setting; Speed Setting; Diameter calculate etc



Model No.	SZX1100-2	SZX1300-2	SZX1600-2
Max. Width(mm)	1100	1300	1600
Max. Speed(m/min)	170	170	170
Min. Slitting Width(mm)	30	30	30
Max. Unwind Dia.(mm)	800	800	800
Max. Rewind Dia.(mm)	650	650	650
Power(kw)	6.5	8.5	12.0
Weight(kgs)	2150	2350	2650
Dimension(mm):L*W*H	3300*2100*1500 2500*1300*900	3500*2100*1500 2700*1300*900	3800*2100*1500 3000*1300*900



1.Has several senior engineers service in many countries, all the year round with our after-sales office in multiple countries.

2.Machines with good quality in one year, life-long maintenance.

3.Has many machines can be monitored via the Internet, solve customer requirements in a timely manner.

4.Has several senior,continuous innovation and reform, in order to ensure the quality of mechanical stability.

5.Undertake various non-standard machinery, solve the customers' requirements.
