SMA female to UFL /IPEX male adapter sma female to ufl connector

Product Overview

Description

SMA female to UFL /IPEX male adapter sma female to ufl connector



SMA female to  U.FL /IPEX male adapter rf coaxial connector,sma to u.fl adapter

Key Performance
Temperature range		-65~+165	Insulation resistance		≥5000MΩ
Characteristic impedance		50Ω	Dielectric Withstanding voltage		1000V(r ms)
Frequency range	With flexible cable	0~12.4GHz	Contact resistance	Center conductor	≤3mΩ
	With semi-rigid/flexible cable	0~18GHz		Outer conductor	≤2mΩ
VSWR	With flexible cable	≤1.15+0.02F	Durability		500 Cycles
	With semi-rigid/flexible cable	≤1.05+0.02F
Material And Plating
Body		Brass , gold plated or stainless steel passivated
Male center contacts		Brass , gold plated
Female center contacts		Beryllium copper , gold plated
Insulators		PTFE
Gaskets		Silicon rubber
Crimp ferrules		Copper alloy , gold or nickel plated
