Product Overview

Description

AP-DC2452-80 overhead ionizing blower is one of the ionizing blower product series manufactured by Shanghai Anping Static Science&Technology Co.,Ltd.,

AP-DC2452-80 overhead ionizing air blower applies the DC current ion synchronous transmitting technology. High volume of positive and negative ion are generated by two independent transmitting electrode with direct current corona discharge and arrive the object surface where the static to be eliminated most equally. Eliminate static and control the remaining static under international standard.

AP-DC2452-80 is widely used in electronics,plastic,chemical,printing and optics industry etc.

Features:

1,Fit for static elimination in large area

2,The combination of multi-units independent ion transmitting

3,Stepless adjustment of the air volume and longer lifetime of the fan

4,Fast speed of the elimination and stable performance of the circuit

5,Detachable cover net both front and back, convenient to clean and maintain



Industry Applications

Wildly used in electronics, optoelectronics, semiconductors, plastics, films and printing industries.



Specificion:

Type	AP-DC2452-80
Input Voltage	AC 220V /50Hz or 110V/60 Hz
Output Voltage	±DC4000V-DC7000V
Power	25W
Effective working range	920*600(L*W)
Discharge speed	≤3S (450mm testing center from the air outlet)
Ion balance	≤ |±10V |(450mm testing center from the air outlet)
Air volume	0~95CFM
Noise	≤ 60db (150mm from the air outlet)
Ozone thickness	≤ 0.02 ppm (150mm from the air outlet)
Working temperature	0 ~ 50°C
Dimension	840*175*124mm(L*W*H)
Net weight	3930g
Gross weight	5430g (including packaging accessories)
Test Data
Test standard	ANST/ESD.STM3.1 ANST/RSD.SP3.3  SJ/T 11446-2013
Test instrument	Trek157
Test voltage	±1000V→100V
Test environment	Relative humidity:50±5%
	Temperature:23±3℃



Q&A

Payment Term	T/T, L/C, West Union, Paypal
Delivery Time	3 to 5 working days after confirm the order
Warranty	2 years after delivery
Package	Carton
