Product Overview

Description

  parking lot solutions card dispenser and ticket dispenser car parking system

SEWO PMS Working Steps:

How To Entry ?

Step 1----- The Vehicle covers the 1th Loop coil.

Step 2 ----- Driver press the push button on the entry parking case.

Step 3 ----- The card dispenser spit an RFID Card. system recording all the information.like data.entry time.

Step 4 ----- Boom barrier open automatically

Step 5 ----- After driver pass the 2th loop coin. The Boom barrier close automatically



How To Pay and Exit ( For Manual Payment )?

Step 1----- Vistor drive to the payment centre station and give his to the operator (Station near the Exit point )

Step 2----- Operator put  the card in the card issue device

Step 3----- System shows the card information on the LED display automatically.

       Including The card holder. How long the car stay inside the parking system. How much need to pay

Step 4----- After driver pay the cash. Operator click " open barrier ". then boom barrier open

Step 5----- After the car pass the loop coil. the boom barrier close



How To Pay and Exit ( Auto-Payment Station ) ?

Step 1----- Vistor drive to the Auto-payment Station and place card on the reader

Step 2----- The auto-payment machine show how long the car stay and how much need to pay

Step 3----- Vistor Insert Coin or Notes to the bill acceptor then print out receiption

Step 4----- Vistor take the card to the exit point and place on the reader. then barrier open automatically

Step 5----- After the car pass the loop coil. the boom barrier close









Advanced Features

-- Automatic RFID Card / Barcode dispenser

-- Housing with waterproof. Dustproof and rustproof design

-- Easy to install. Debug and maintain. Testing function available

-- Multi network modes to realize remote data and image transmission

-- Compatible with Long distance reader function.. Off-line working available

-- 13.56MHZ.125KHZ.Barcode.RFID.UHF.Bluetooth available in one control board

-- Flexible system configuration.extended to multi-level parking lot management system





Parameters

Model	SEWO-T9 parking camera system
Dimension	240*290*1360mm
Housing Material	Steel & Tempered glass
Housing Color	Yellow/blue
Support Built-in Reader	IC/ID. Barcode. RFID
Com Mode	RS485. Rear TCP/IP
Communication distance	1200m(RS485)
Data Transmission speed	4800bps/100m
Offline storage Capacity	10000pcs(Extendible)
Blacklist Capacity	1000pcs(Extendible)
Card Capacity	1000pcs(Extendible)
Working Temperature	-30°C--70°C
Working Conditional	Indoor / Outdoor



SEWO Patent Gate Barrier Optionals







SEWO-T9 / T6 Parking Machine









SEWO-T9Automatic Payment





Parking Software Real-time Monitoring





Parking Software T9 Enginnering  Projects
