LXTL-2 Vacuum and Centrifugal Turbine oil purifier used engine oil recycling machine waste oil recycling machine
Application:
LXTL vacuum and centrifugal turbine oil purifier is specially used to process turbine oil. On one hand, it can centrifugally separate the water and impurities in large amount contained in the turbine oil without filtration elements consumption; on the other, it can remove tiny moisture, impurities, gas and soluble acid by vacuum separation system, to regenerate lubrication ability of turbine oil and ensure turbine units safe and stable operation.
Working Principle:
If the turbine oil is polluted by large amount of moistures and impurities and need to be filtered and purified, cyclic centrifugal separation would be firstly adopted by the centrifugal oil separation system in order to separate large water and particulates from the turbine oil to make them reach about 0.5% (water content) and 0.1% (impurities content).
After separating large amount of water and impurities by centrifugal oil separation system, the vacuum system can remove the rest tiny moisture.
Technical Parameter:
Item
Unit
LXTL-1.5
LXTL-2
LXTL-3.5
LXTL-5
Flow Rate
m3/h
1.5
2
3.5
5
Vacuum Degree
Mpa
-0.06~-0.095
Working Pressure
Mpa
≤0.5
Operating Temperature
℃
≤30~80
Power Supply
380V 50Hz 3 Phase 4 Wire (Can be customized)
Heating Power
KW
18
24
36
48
Total Power
KW
23
31
45
60
Inlet(outlet)diameter
mm
Φ32
Φ32
Φ38
Φ42
Weight
kg
730
850
1150
1650
Overall
Dimensions
L
mm
1550
1650
1700
1750
W
mm
1200
1250
1300
1350
H
mm
1600
1700
1700
1700
Characteristics:
1. Combines centrifugal oil separation technology with vacuum filtration technology, enhance the ability of removing water, gas and heavy particulates.
2. No filter elements consumption, reduce using cost.
3. Pressure protection system reminds of cleaning dirt. Make sure a safe and stable running.
4. Movable and flexible, can be used for outdoor work.
