2W500 50 water valve solenoid 50mm normally open

water valve solenoid 50mm normally open

working medium : air,water,oil,gas

Aperture of Flow Rate : 40mm

Cv Value : 29

Joint Pipe Bore :   1-1/4"

 Operation Fluid Viscosity : below 20 CST

 Working Pressure : 0~20 kgf/cm2

Max.Pressure Resistance : 35 kgf/cm2

Operating Temperature Range : -5~80℃

Voltage: DC12V,DC24V,AC24V,AC36V,AC110V,AC220V,AC380V

Voltage Range : ±10%

Material of Body : Brass M

aterial of Oil Seal : NBR , EPDM , VITON
