EGA efficient bioreactors/ integrate equipment waste water treatment plant
- Category: >>>
- Supplier: Jiangsu Yulong Environment Protection Co. Ltd.
Share on (60392172605):
Product Overview
Description
1. Product introduction
EGA Efficient bioreactors process using AO+MBBR+BAF technology, removal the organic matter, ammonia nitrogen and total nitrogen pollutants rely mainly on the biological treatment technology of the reactor.
EGA efficient bioreactor using automatic control, with manual operation function. USE the programmable controller (PLC) automatic control system for water pump, mixer, blower, etc. the operation of the mechanical and electrical equipment. Control cabinet with functions of automatic switch, fault alarm, etc. For projects of high control requirements, can chain with central control system according to the engineering practice needs.
2. Product Parameter
project indicate | designed inlet |
designed outlet
| removal rate(%)
|
BOD(mg/l) | 150-250 | ≤10 | 93.3-96 |
COD(mg/l) | 300-350 | ≤50 | 85-90 |
SS(mg/l) | 150-300 | ≤10 | 93.3-96 |
ammonia nitrogen(mg/l) | 30 | ≤5(8) | 85 |
total nitrogen(mg/l) | 50 | ≤15 | 70 |
total phosphorus(mg/l) | 3 | ≤0.5 | 83.3 |
PH | 6-9 | 6-9 | - |
3. Product type selection
type |
treatment capacity (m3/d) | Dimension
(L×B×H)m | Installed power (KW) | Service power
(KW) | occupied area (m2) |
EGA-25 | 25 | 4.6×1.5×2.0 | 2.58 | 1.66 | 7.0 |
EGA-50 | 50 | 6.0×2.0×2.0 | 3.30 | 2.20 | 12.0 |
EGA-100 | 100 | 8.0×2.2×2.4 | 6.00 | 3.75 | 18.0 |
EGA-150 | 150 | 9.6×2.4×2.8 | 8.10 | 5.15 | 23.0 |
EGA-200 | 200 | 12.0×2.6×2.8 | 9.20 | 5.90 | 31.0 |
EGA-300 | 300 | 12.5×3.0×3.0 | 14.00 | 8.50 | 37.5 |
EGA-400 | 400 | 10.0×3.0×3.0 (2 units) | 19.20 | 11.50 | 60.0 |
EGA-500 | 500 | 12.0×3.0×3.0 (2 units) | 26.20 | 15.70 | 72.0 |
EGA-1000 | 1000 | 12.0×3.0×3.0 (4units) | 43.50 | 27.00 | 145 |
Specifications of the EGA high efficient bioreactor, user can combine a few units in parallel according to the actual treatment water capacity of the project, also can separately designed and select type according to customer and actual project requirements.
EGA efficient bioreactor can use SUS304 platen forming according to user needs, also can use the materials such as carbon steel, glass reinforced plastics forming.
