IGBT DC Inverter 3phase high frequency heavy duty digital synergic CO2 gas GTAW/SMAW/mig/mag twin pulse aluminum welding machine
- Category: Welding Equipment >>>
- Supplier: Keyue Welding Equipment Co. Ltd.
Share on (60394476967):
Product Overview
Description
Product description
Product feature
- Supporting: MIG/MAG, Pulse MIG(single&double), Lift TIG, MMA, Gouging
- Controlling: Synergic with over 100 programs
- Protection: Over current, over voltage, under voltage, over heat and wire blocked
- Assembling: Source, Wire feeder, Water tank and trolley combined in one
- Material: Mild steel, Stainless steel, aluminum and aluminum alloy(special)
| Model | MIG-350H |
| Input voltage(V) | 3PH AC380V±15% |
| Input power(KVA) | 13.8 |
| Input current (A) | 21 |
| Rated output | 31.5V/350A |
| Output current(A) | 25-350A |
| No-load voltage (V) | 96±5 |
| Duty Cycle% (40℃ 10min) | 350A 60% |
| 271A 100% | |
| Efficiency (%) | 80 |
| Protection grade | IP21 |
| Insulation grade | F |
| Net weight (KG) | 42 |
| Gross weight (KG) | 45.5 |
| Gross weight of WF(KG) | 43.3 |
| Gross weight of trolley (KG) | 47 |
| Dimension of trolley package (mm) | 1020*520*360 |
| Dimension of WF package (mm) | 690*370*460 |
| Dimension of machine (mm) | 650*340*890 |
| Dimension of package (mm) | 740*400*910 |
Performance
Material | Sheet thickness (mm) | Stick diameter (mm) | Current range(A) | Model |
Carbon steel Stainless steel Low alloy steel
| ≥0.8 | 0.8/1.0 | 50-200 | MIG-200 |
≥0.8 | 0.8/1.0 | 60-250 | MIG-250 | |
≥0.8 | 1.0/1.2 | 60-350 | MIG-350 | |
≥0.8 | 1.0/1.2/1.6 | 60-500 | MIG-500 | |
Carbon steel Stainless steel Low alloy steel Aluminum
| ≥0.8 | 0.8/1.0 | 30-185A | MIG-200P |
≥0.8 | 2.5/3.2/4.0/5.0 | 25-350 | MIG-350H | |
≥0.8 | 5.0/6.0/8.0 | 25-500 | MIG-500H |
