QL HA300 H2 and pure air in one machine hydrogen air generator

Product Overview

Description

Combined H2&Air Generator for Gas Chromatograph in Lab



Model: QL-HA300, QL-HA500



Introduction

QL series hydrogen & air generator is an equipment which integrates QL series hydrogen generator and air generator together. It can supply H2 and pure air together at the same time. It utilizes PEM technology to produce high-purity hydrogen gas, no needing any chemical. No corrosion, no pollution.



Features



Compact structure, easy to operate, It can work well with all kinds of GC instrument.





Technology parameters



Model	QL-HA150		QL-HA300		QL-HA500
Gas Type	H2	Air	H2	Air	H2	Air
Flow rate        (ml/min)	0-150	0-3000	0-310	0-3000	0-510	0-3000
Output pressure    (MPa)	0-0.4
Power voltage      (V)	220±15%V   50~60Hz
Power Consumption (W)	< 250		<300		<450
Weight            (kg)	<45
Dimension    (L*W*H)mm	440×485×350
