automatic offset paper numbering machine,numbering printing machine,automatic numbering printer

automatic offset paper numbering machine,numbering printing machine,automatic numbering printer

Price:RUB 230,305.80 - RUB 307,074.40

Price in USD:Details

Quantity:

numbering stamp,offset printing and numbering machines,perforating machine

Features of numbering stamp :

1. Lateral and Vertical Perforation can be done at the same time;

2. Perfect Numbering Position & Legible Print with resin plate printing;

3. Numbering Speed up to 8,000 sheets per hour;

4. LCD computer controlling system is optional

5. Brand Parts: France Components (Schneider) & Japanese Bearings (NHK);

6. Oil Free Vacuum Pump adopts Japanese Technology;

7. Positive Limitation Protection is adopted to make sure safe operation;

8. Automatic Powdering & Blower system;

9. High quality Feeding Rubber-tired & Double Sheets Detection Device;

10. Chrome plated Technology and Stainless Steel Material are used to protect the roller

Technical data of numbering stamp :

Model	XHDM480	XHDM570	XHDM630
Max. Paper Size	470x360mm	560x400mm	620x440mm
Min. Paper Size	180x150mm
Paper Weight	28-250gsm
Printing Speed	2000-8000 sheets/hour
Ink Roller	6 rollers(ink form rollers: 2pcs)
Number capacity:	Lateral: 7 row x 7 column=49 Vertical: 5 row x 8 column=40	Lateral: 7 row x 8 column=56 Vertical: 5 row x 10 column=50		Lateral: 7 row x 9 column=63 Vertical: 5 row x 11 column=55
Perforation	Min. space between lateral perforating knives: 10mm Min. space between vertical perforating knives: 30mm
Power for main motor	0.75KW	0.75KW		1.5KW
pump motor power	0.75KW
Power Supply	220V/50HZ
Dimensions	1780x935x1120mm	1900x1020x1120mm		2060x1150x1120mm
Net Weight	280kg	320kg		370kg

Model	XHDM720
Max. Paper Size	720x440mm
Min. Paper Size	180x150mm
Paper Weight	28-250g
Printing Speed	2000-8000 sheet/hour
Ink Roller	6 rollers(ink form rollers: 2pcs)
Number capacity:	Lateral: 7 row x 10 column=70 Vertical: 5 row x 12 column=60
Perforation	Min. space between Lateral Perforating knives: 30mm Min. space between Vertical Perforating knives: 25mm
Power for main motor	1.5KW
Power for pump motor	1.5KW
Power Supply	220V 50HZ
Dimensions	2060x1170x1120mm
Weight	800kg
