Product Overview

Description

Samsung LG5630/5730 Module IP65 For Signs And Channel Letter Lights





3*5730 led module, dc 12v 1.5w/pc, 100pcs/bag









1. Main Data

DC 12V  1.5W/pc   constant voltage

20pcs/string, 100pcs/bag, 2000pcs/carton

ABS injection material + expoy resin

IP65 waterproof

Leadtime  3-7 days

Warranty   3years

Colors available 6000-6500K, 3000-3500K, 4000-4500K, red, green, blue, yellow



2. Features

Take TOP 5730 LED as light source, no light spot, low decay and good consistency.
Low consumption, high brightness, free maintenance, long life span.
beautiful and unique appearance, good heat dissipation. Protect level:IP65
Input voltage: DC12V, reliable and safe.
With series-parallel connection circuit for LED PCB, 20pcs modules are connected to one string and each module can be cut individually.
Easy installation with double-sided adhesive tape backing on modules
Certifications CE ROHS



3.  Applications

channel letter lighting

backlight for banner

advertising signs

light box







4.  More Pictures
