CE Approved DWC 520 Binding Machine Semi auto Double Wire Book Binding Machine For Book

Share on (60402894368):


Price:RUB 512,856.99 - RUB 557,453.25

Quantity:


Product Overview

Description

DWC-520 Binding Machine Semi-auto Double Wire Book Binding Machine For Book


Book Binding Machine



Book/Calendar Binding Machine

1) Use Panasonic PLC Control

2)Binding sizes:1/4''-1 1/4''
3)Binding length:520mm
4)CE certificate

Book/Calendar Binding Machine



Also called wire-o binding machine/ double wire binding machine. It's the perfect binding for calendars,catalogues,notebooks and diaries etc. It's 5 to 10 times faster than manual binding !





Specification:



MODEL



DWC-520A

Feeding Model



Manual

Handing of Double Wire



Automatic cutting,insertion&closing

Wire Specifications



Diameter1/4"-7/8"      Pitch 4:1",3:1",2:1"

Max.Paper Width (mm)



520

Max.Binding Width (mm)



507

Min.Paper length (mm)



75

Working Speed (cycles/hy )



1000-1300

Power Supply



220V/1ph/50Hz

Air Compressor(not included) (kw)



1.5

Air Pressure (bar)



6-8

Machine Dimensions (mm)



1030(L)x770(W)x1200(H)

Outside Wooden Box Dimensions (mm)



1480(L)x1050(W)x1570(H)

Net Weight (kg)



250

Gross Weight (kg)



350

Dimensions of Pay-off Unit (mm)



490(L)x760x1220

Neet Weight of Pay-off Unit



65
