10kva 10kw 12kva DG silent air cooled diesel generator
- Category: >>>
- Supplier: Elephant Tech Fuzhou Co. Ltd.
Share on (60403689059):
Product Overview
Description
| Features: | |
| * The lightest and smallest among the gensets with same output. | |
| * Full automatic generator protection system | |
| * Special dual protection system | |
| * Unique unloading system for stopping of engine | |
| * Steady frequency-governing ratio ≤ 3%, complying with military standard | |
| * Automatic transfer switching, remote monitoring, to realize guardless by human | |
| * Low noise, only 70dB/7m | |
| * New patent design, low inner housing temperature, stable output and good reliability | |
| * Options: universal-direction wheel, ATS, R485 standard communication connection | |
| * Electric self-suction fuel pump, Heater | |
Model | DG12000SE |
Rated Frequency(Hz) | 50 60 |
Rated Output(Kva) | 10 11 |
Max. Output(Kva) | 11 12 |
Rated Voltage(v) | 230 240 |
Rated Current (A) | 43.5 45.9 |
Phase Number | Single |
Power Factor(cos ) | 1 |
Insulation Grade | F |
Pole Number | 2 |
Excitation Mode | Brush, Self-excitation and Constant Voltage (AVR) |
Panel Type | Intelligent |
Output Socket | Single-phase socket,wiring terminal |
DC12V Output | 12V, 8.3A |
Noise Level (7M)db(A) | 70 |
Structure Type | Fully closed |
Engine Model | R2V840 |
Engine Type | V-twin, two-cylinder, 4-stroke, DI |
Cylinder No. - Bore x Stroke (mm) | 2-86x72 |
Displacement (cc) | 836 |
Rated Power [kW(Hp)/(r/m)] | 11/3000 12/3600 |
Compression Ratio | 20:1 |
Cooled System | Air-cooled |
Lubrication System | Pressure & Splashed |
Starting System | Electric Starter |
Fuel Type | 0#(summer) -10#(winter)-35#(cold winter) Light Diesel |
Lube Oil Brand | SAE10W30 (CD Grade above) |
Lube Capacity (L) | 1.7 |
Starting Motor Capacity (V-kW) | 12V 1.4kW |
Charging Generator Capacity (V-A) | 12V 8.3A |
Battery Capacity (V-Ah) | 12V 36Ah |
Fuel Consumption (g/kW·h) | ≤285 ≤320 |
Fuel Tank Capacity (L) | 21 |
Continuous Running Time (Hr) | 7 6.5 |
Overall Dimension: L x W x H (mm) | 1040 x 660 x 740 |
Weight (Kg) | N.W.: 245 G.W.:250 |
