10mm Ultra Thin LED Panel Light Samsung 100lm/W 36W LED Panel Light 600x600 (620x620)

Product Overview

Description

Ultra Thin LED Panel Light, Samsung 100lm/W 36W LED Panel Light 600x600



LED Panel Light is special design for office lighting, with good color redering, high brightness and flicker free.

Ultra slim design with thinkness of 10mm. Adopted branded LED Source and Driver, high lumen of 100lm/w and long life of 50000hours.



1. High effeciency 100lm/w;
2. Samsung SMD 2835 LED, CRI82;
3. Safety working voltage: DC36~42V;

4. Ultra slim construction (thickness only 10mm)
5. Flicker-Free Lighting: Eliminate eye strain and headaches



LED Panel Light Data sheet:



Code	Specification
	Size (MM)	LED Type	LED Qty	Total Power	Lumen Output	Input
P606036W	595X595X10mm	SMD2835	168PCS	36W	3200-3400lm	100-240V~
P606042W	595X595X10mm	SMD2835	192PCS	42W	4200-4400lm	100-240V~
P1203036W	1195X295X10mm	SMD2835	168PCS	36W	3200-3400lm	100-240V~
P1203042W	1195X295X10mm	SMD2835	192PCS	42W	4200-4400lm	100-240V~
P1206072W	1195X595X10mm	SMD2835	384PCS	72W	5800-6100lm	100-240V~





Packing Details





600x600:     Carton Size:   670x660x225mm / 6pcs.     Gross Weight: 28KG

1200x300:   Carton Size:  1263x243x378mm / 6pcs.   Gross Weight: 30KG

1200x600:   Carton Size:  1284x684x278mm / 4pcs.   Gross Weight: 40KG
