eight Parameter | Complete Vehicle Kerb Mass(kg) | 3290 | ||
Maximum authorized total mass (kg) | 5480 | |||
Dimension Parameter | External Dimensions(mm) | Length | 5850 | |
Width | 2250 | |||
Height | 2970 | |||
wheelbase(mm) | 3250 | |||
Minimum Ground Clearance(mm) | 240 | |||
Performance Parameter | Maximum Speed(km/h) | 75 | ||
Economical Speed(km/h) | 60 | |||
Maximum Gradeability(%) | >30 | |||
Turning diameter(m) | 13 | |||
Recommended Configuration | Engine | Engine Type | YN38PE-2 | |
Rated power(kW)/Rev(r/min) | 87/3000 | |||
Maximum Torque(N*m)/Rev(r/min) | 340/1800~2200 | |||
Transmission | HW50508C | |||
Clutch(mm) | 325 | |||
Rear Axle | Type | HGZ072QB | ||
Speed Ratio | 6.33 | |||
Fuel Tank(L) | 160 | |||
Chassis Cross-section(mm) | 800×250×70×(7+4) | |||
Suspension(Front,Back) | 11/12+9 | |||
Tyre | 8.25R16 | |||
