Вакуумный доильный аппарат, Электрический вакуумный воздушный насос

Product Overview

Description



Vacuum Milking Machine Electric Vacuum Air Pump





Quick Details:

- Model: HL-V550

- Capacity: 550L

- Material: cast iron

- Vacuum pump vane: fiber material vane

- Range: used for milking machine and milking parlor system



Specification:



Capacity (L/min)	250	300	550	850	1500	2100
Pump Speed (r/min)	1440	1440	1440	1440	1440	1440
Vacuum Degree(Kpa)	50	50	50	50	50	50
Noise (Db(A))	≤50	≤50	≤60	≤70	≤70	≤70
Ultimate Vacuum(Mp)	≤90	≤90	≤90	≤90	≤90	≤90
Motor Power(kw)	1.1	1.1	2.2	3	4	5.5
Weight(kg)	13.5	14	31	36	57.5	69.5
Size(L×W×H) (mm)	230*220*220	230*220*220	280*270*220	300*220*220	430*230*230	390*290*290



Note: The above parameters for reference only!





Description:

The electric vacuum air pump is the heart of the milking machine. Regular servicing helps preserve the vacuum reserve. Various capacity electric vacuum air pump with different motor power be supplied for choosing. The heavy duty body of the electric vacuum air pump is constructed from chemical resistant cast iron, making it durable to any environmental working conditions.



The function of electric vacuum air pump is to extract air from the milking machine system through the belt driven. This electric vacuum air pump gives flexibility with speeds ranging from about 800–1500 r/min and a corresponding angel of pump capacities to suit different sizes of milking machines.



One whole set electric vacuum air pump consists of vacuum pump, silencer (stainless steel muffer), oil can (oil pot), belt (pulley) and some rubber parts. And the pump vane of vacuum pump kits is made of fiber material.





Features:

- Vacuum air circle fast; under low pressure it can still maintain a high pumping speed.



- There is OIL MIST FILTER in the outlet,  vacuum pump oil could recycle using.



- Built-in automatic back valve, comfortable and reasonable appearance design.



- Reasonable silencer to reduce the noise; low noise, low vibration.



- Perfect oil pot / oil can, could help in saving oil.



-  Compact structure, small size, save a space.





Application:

The electric vacuum air pump, be used to extract air from the milking machine system through the belt driven, is the heart of the milking machine. It is suitable for milking parlor, automatic milking system and milking machine.
