                                Nonwoven Box Bag Making Machine With Handle Attached









Product Introduction:



This machine is suitable for non woven fabric material only, it is the most advanced equipment and has the function of full automatic handle loop sealing. The speed is about 20-120 pcs/min, it equals to 5 workers operating 5 handle sealing machines. It can fully automatic make non woven bag products with different bag type and size, as handle attached bags,box bag, T-shirt bags (vest bags), flat bags, drawstring bags and so on. It has widely used in clothing, footwear, wine, gifts packaging etc. The machine can instead of the traditional hand-sewing and reducing labor and manufacturing costs. It’s very popular in worldwide.





Main Technical Parameter





Non Woven Bag Making Machine Type	HBL-DC600	HBL-DC700	HBL-DC800
Bag Making Speed	20-120pcs/min	20-120pcs/min	20-120pcs/min
Handle Bag Speed	20-55pcs/min	20-55pcs/min	20-55pcs/min
Bag Length	100-800mm	100-800mm	100-800mm
Bag Width	200-480mm	200-580mm	200-680mm
Bag-Making Thickness	30-100g	30-100g	30-100g
Power Supply	380V/220V	380V/220V	380V/220V
Total Power	12-17KW	12-17KW	12-17KW
Overall Dimension (L*W*H)	10.3m*2m*2.1m	10.3m*2m*2.1m	10.3m*2.2m*2.3m
Weight	2500KG	2800KG	3000KG







 Features:



1. This machine adopts Taiwan touch screen computer display, PLC computer program which can be edited.
2. Auto meter counting &stopping, could freely setting number.
3. Computer Fixed-length, printing color mark track orientation, Auto-stop when complete.
4. High voltage static processor, Auto constant temperature heating controller.
5. This machine has the function of automatic punching.

6. Unwinding magnetic powder tension control with manual, Auto side-correction control.
7. This machine adopt ultrasonic welding of all aspects, bag mouth folding welding, side sealing, once full completed, fast speed, easy to operate, firm sealing, beautiful and decent.



Production Detail:



 Sample bags











Multi-function non woven bag making machine

1. Flat bag (D-cut bag) (Online make)
2. Flat bag with bottom gusset (Online make)
3. T-shirt bag (vest bag,U-cut or W-cut) (Need punching machine)
4. Handle bag (Online handle sealing machine)
5. Box bag (Online handle sealing machine)
6. Shoes bag (Rope wearing bag)
7. Laminating bag



Buying Guides





Dear buyer,
In order to offer you the best suitable machine, better to offer the following specifications before you sending us the inquiry. All suppliers can send you the sample quotation, but we hope to send you the best offer after we getting your clear requirement.



1. Which kind of bags you want to produce? (pls. study your market well)
2. What is the max dimension of bag's width and length?
3. Will you need to print color on bags?







 We have three type of nonwoven bag making machine:



1: HBL-DC700 type:  it can make bags Box Bag ,Handle Bag ,Shoe Bag , D cut Bag directly   (1245)                                                                                 T shirt bag need to add punching(3)



2: HBL-C700 type:  it can make bags Box Bag ,Shoe Bag , D cut Bag directly   (145)                                                                                                      T shirt bag need to add punching (3)
                                                          Handle Bag need to add punching (2)

1: HBL-B700 type:  it can make bags Shoe bag , D cut bag directly  ( 4 5 )

                                                          Handle bag need to add handle sealing machine(1)

                                                          T shirt bag need to add punching (3)









Exhibition



 Company information





Certification





Product Packaging







Contact detail





After sale service





1. How long will your engineer reach our factory?
Within one week after machine arrival your factory.





2. How many days will you finish installing ?
We will finish installation and training within 15days.





3. What should we charge for your engineer?
You should charge for the cost of our engineer's visa , air tickets, hotel, food ,and also their salary 50USD one day per person.





4. How long is your machine's warranty period?
All our machine have one year guarantee, starting from finished installation.





5. How could we do after one year warranty period?
We also can do service for you, but you need pay salary for my technician 70USD/day.





6. How could we do if the parts broken within warranty?
We would express the free replacement parts during the warranty date.





7. Does your engineer understand English?
Our engineer understand a little English. All our engineer have more than five years machine installation experience. In addition, they can use body language to communicate with customer.





8. Can you help us find any engineer in our location?
Of course, we will check and inform you as soon as possible.





9. How do we solve the machine problem after your engineer leaving?
Generally speaking, there will be no problem after finish installing. In case you have any problem. You can contact our sales at any time. Our engineer will take a solution video according your description.





10. How many worker do we need running those machines?
Except Two for bag making machine, flexo printing, slitting, ultrasonic sewing, hydraulic punching machine only need one person for each.
