1000m3 grain storage steel silo

Product Overview

Description

1000m3 grain storage steel silo



Bottom shape	Flat Bottom Type
Capacity	≥1500t
Design view	Can be built by hopper concrete or flat cement based on your requirement and actual demand.
Silo Discharge	There will be one or more discharge holes on the bottom based on different materials and capacity.
Sweeper	Clean up residual easier China Famous Brand or France Brand

• It is popular with its simple structure,large capacity,various ways of unloading.Easy for  maintenance and repair.


• Wide Range of BODA silo Products include different models of flat bottom silos, diameters of   which varies from 6.417 m. to 32 m. and capacity up to 22.648 m³.


• This kind of silos are with larger capacity,which are easily installed and cost less.


• There are many ways of unloading,such as the fluidized unloading,multi-spot unloading,sweep auger and manual cleaning etc...


• The concrete conical bottom is also available for discharging.Flat bottom silos are widely used in grain mills,some of them can be used in oil,feed,flour,starch,brewage and port or grain storage industrial lines.



• Silo: the silo wall sheets are corrugated that is made of high quality galvanizing board; the sheets are bolted together by common or high strengthen bolts. The thickness of silo wall is designed according to the strength theory, which makes the whole wall can afford even swelling tension. At the same time, the interior vertical stiffeners can afford the vertical friction. It is 0.96m between every two stiffeners, the cutting face is in the shape of "V", and there are spherical waterproof washers in the bolts' hole and water proof mastic bars between every two pieces of silo sheet. The handle equipments can make it more convenient to maintenance and unloading, such as silo doors, interior and exterior ladder and protecting net.



•  Radial beam silo roof support system: the roof is made of galvanizing board that is 0.8mm thick, and bolts are with galvanizing die. There are special equipments on the silo roof such as natural vents, manhole, roof ladders, and secure cages and so on.

• The main parts of the silo bin and roof are made of galvanizing board or spares which can make silo become even more steady and durable with longer life time, which is good to realize automatic work.



        hopper bottom steel silo       insulation silo           stainless steel silo             welding steel silo
