Product Overview

Description





Products Description




YW Vertical Submersible Manure Sewage Pump

1.Brief Introduction
YW Type non-clogging liquid portable sewage pump adopts unique single-blade or double blade round structure, which greatly enhanced the ability of dirt through the effective diameter 5 times of that of pump inlet or solid particle that diameter is 50% of that of pump inlet. Mechanical seal using a new type of tungsten carbide hard material, at the same time changed the seal to dual-sealed, so that to make it running long time in the oil interior, enable the security operation. It has Vertical structure, because the pump body is submerged in the liquid, it is easy to start, no exhaust problem. The depth can be 0.5 to 5 meters under the liquid.

2. Technology Parameters

Flow: 8-2600m3/h

Head: 5-60m

Power: 0.75-250kw

Rotary speed: 580-2900r/min

Calibre: 25-500mm

Temperature range: ≤60


Model(mm)(m3/h)(m)
Turn soon(r/min)
Power(kw)
Efficiency(%)
25-8-22-1.1
2825
1.1
38.1
32-12-15-1.1
2825
1.1
40
40-15-15-1.5
2840
1.5
45.1
40-15-3-2.2
2840
2.2
48
50-20-7-0.75
1390
0.75
54
50-10-10-0.75
1390
0.75
56
50-20-15-1.5
2840
1.5
55
50-15-25-2.2
2840
2.2
56
50-18-30-3
2880
3
58
50-25-32-5.5
2900
5.5
53
50-20-40-7.5
2900
7.5
55
65-25-15-2.2
2840
2.2
52
65-37-13-3
2880
3
55
65-25-30-4
2890
4
58
65-30-40-7.5
2900
7.5
56
65-35-50-11
2930
11
60
65-35-60-15
2930
15
63
80-40-7-2.2
1420
2.2
52
80-43-13-3
2880
3
50
80-40-15-4
2890
4
57
80-65-25-7.5
2900
7.5
56
100-80-10-4
1440
4
62
100-110-10-5.5
1440
5.5
66
100-100-15-7.5
1440
7.5
67
100-85-20-7.5
1440
7.5
68
100-100-25-11
1460
11
65
100-100-30-15
1460
15
66
100-100-35-18.5
1470
18.5
65
125-130-15-11
1460
11
62
125-130-20-15
1460
15
63
150-145-9-7.5
1440
7.5
63
150-180-15-15
1460
15
65
150-180-20-18.5
1470
18.5
75
150-180-25-22
1470
22
76
150-130-30-22
1470
22
75
150-180-30-30
1470
30
73
