Fomblin Y L VAC 25/6 replacement Perfluoropolyether oil with NSF certificate

Share on (60417800305):


Price:

Quantity:


Product Overview

Description


Product Display

Product Display&Details

Equivalent Brand: Fomblin

Brand

Typical

RUI

606

1406

1606

2506

1808

2509

40011

140013

Fomblin

06/6

14/6

16/6

25/6

18/8

25/9

40/11

140/13



Property

RUI PFPE oils are perfluorinated polyether inert fluids for use as lubricants in vacuum pumps.RUI fluids are a mixture of fluorinated polymers obtained by a photochemical process that begins with hexafluoropropylene. These fluids have exceptional properties such as:



Low vapor pressure

Low toxicity

Chemical inertness

High dielectric properties

High thermal stability

Low surface tension

Good lubricant properties

Good radiation stability

No flash or fire point

 Environmentally acceptable

Good aqueous and non-aqueous solvent resistance

Excellent compatibility with metal

plastics and elastomers



Features

Will not polymerize when exposed to oxygen,ionizing radiation or accelerated subatomic particles. The system stays free of varnish and deposit from fluid decomposition.

Non-flammable

Resistant to oxidation of explosion and hot fluid can be exposed repeatedly to air without harm to the fluid while running the pumps.

Inert to most reactive chemicals,the fluid can be used in direct contact with materials such as UF6,F2,PCl3,BF3,without harm to the fluid.



Technical Index

Typical Property

 Unit

RUI(PFPE) M

606

1406

1606

2506

Average molecular weight

a.m.u.

1800

2500

2700

3300

Specific gravity(@20℃)

g/cm3

1.88

1.89

1.89

1.90

Kinematic Viscosity

cSt

64

148

168

276

Vapor pressure

@25℃

torr

8×10-7

1×10-7

2×10-6

6×10-8

@100℃

torr

3×10-3

2×10-4

2×10-4

6×10-5

Pour Point

-50

-45

-45

-35

Heat of vaporization(@200℃)

cal/g

11

8

8

7

Surface tension

dyne/cm

21

22

22

22

Evaporation loss, (22hrs)

%by wt.

2.8(120℃)

2.6(149℃)

3.9(149℃)

0.6(149℃)

Ultimate total pressure

torr

1.7×10-3

1.4×10-3

2.4×10-3

1.2×10-3

Specific oil consumption

cm3/hr

0.4

0.6

0.5

0.7



Typical Property

 Unit

RUI(PFPE) H

1808

2509

40011

140013

Average molecular weight

a.m.u.

2800

3400

4100

6600

Specific gravity(@20℃)

g/cm3

1.89

1.90

1.91

1.92

Kinematic Viscosity

cSt

190

285

474

1508

Flash point

None

None

None

None

None

Pour Point

-42

-35

-32

-23

Heat of vaporization(@200℃)

cal/g

9

7

7

5

Surface tension(@20℃)

dyne/cm

20

20

20

20

Refractive Index(n 20D)

/

1.300

1.301

1.304

1.304

Specific heat capacity(@20℃)

cal/g·

0.24

0.24

0.24

0.24



Application

RUI PFPE oils are suggested for applications requiring the highest quality vacuum suchas in scanning electron transmission microscopes, mass spectrometers, particle accelerators, ion implantation, plasma and vapor deposition processes. In addition, it is suggested for pumps handing reactive gases such as UF6, F2, Oxygen, Ozone, and Tritium, as the fluid can be used in direct contact with those gases without reaction and fluiddegradation.



Typical

RUI(PFPE) M

RUI(PFPE) H

606

1406

1606

2506

1808

2509

40011

140013

Rotary pumps-sealing

& lubricant fluid











Turbomolecular    pumps-lubrication















Roots pumps-lubrication













Diffusion pumps-working fluid













Packing and Storage

Available in 1kg plastic drums, 5kg plastic drums

Transport as non-hazardous chemicals, keeping away from rain and sunlight.
