T568 hot sell auto truck tire changing machine

Product Overview

Description

T568 hot-sell auto truck tire changing machine

Features:

1.Semi-automatic truck tyre changer T568

2.Univer self-centering chuck.

3.Clockwise and anticlock wise rotation of chuck.

4.Rim capacity 14"-26".



Technical Data:

Rim Diameter:	14"-26"
Max.wheel weight:	500kg
Max. wheel width:	780mm
Max. Tire diameter:	1600mm
Hydraulic pump motor	1.5kw 380v-3ph (220v optional)
Gearbox motor:	1.8kw 380v-3ph (220v optional)
Bead breaker force:	2500kg
Operation control voltage:	24V
Machine weight approx:	570kg
Overall dimensions approx:	2500*2000mm
power:	220/400 50/60hz 1p/3p Optional
Gross weight:	647kg
Ouside Dimension(L*W*H)	2030*1590*1000



Optional Accessories:

Alu alloy rims protection set

Alu alloy rims protection rings      Tubeless roller



Standard Accessories:
