HDD 4ch Hybrid MDVR 3G 4G GPS WIFI free software CMS/IVMS with LCD screen for vehicle/auto/school bus/taxi/truck/police car 4CH H.264 HDD Mobile DVR Realtime Monitor
- Category: >>>
- Supplier: Dongguan Fuzeer Electronic Technology Co. Ltd. [Guangdong China]Dongguan
Share on (60420669443):
Product Overview
Description
4CH H.264 HDD Mobile DVR Realtime Monitoring with GPS, 3G, 4G, WIFI Optional
FEATURES
-Supports 4 channels AHD 720P
-Supports SD Card/HDD for main recording
-Supports GPS for location tracking(Optional)
-Supports WIFI for video files download (Optional)
-Built-in 3G/4G for live view and remote management (Optional)
-Supports 360 degree anti-vibration
-Supports USB2.0 high speed backup
-Support PC and mobile(Android and iPhone) client remote monitoring
INTRODUCTION
l H.264 Compression,clear image,1~4CH video input,1 composite video output.
l Military-level design, imported special car connector ensures the stability of product.
l Power-off protection by accident:UPS special technology makes DVR work 3 to 5 seconds when cut off the external power supply, to ensure complete video data and avoid file corruption, which is convenient to check accidents.
l GPS,G-sensor acceleration sensor, speed sensor, temperature sensor.
l Digital idea intercom function.
l video:100f/s (PAL);120f/s (NTSC).Video resolution:CIF/ HD1/ D1/720P optional,support up to 2CH D1, 2CH 720P.
l G.726 audio compression format, 4CH audio input, 1CH audio output.
l 6CH alarm input (level input), 1CH alarm output (relay output).
l Communication Interface:RS232 ,RJ45.
l Recording modes: Power-on recording, timing recording, alarm recording, manual recording.
l Video file format: ASF, use VLC player, or playback by software package, 1CH or 4CH simultaneous playback.
l Data Storage: 2.5-inch hard drive and SD card potional. Support hard disk heating, use removable hard disk cartridges. Original Japanese SD card connector.
l Short start time: DVR goes to normal operating mode within 25 seconds when it is started. It supports key start/shutdown DVR, timer start/shutdown DVR, delay shutdown DVR.
l 8-36VDC wide voltage input for all kinds of vehicles; DC 5V/0.5A, 12V/2A output.
l Normal operation8 ~ 10W,standby0.5W.
l Super shock-proof.
lOperating temperature: -25°C ~ +70°C;
Size: 200(L) x160(W) x55(H) mm
Net Weight: 2070g
Gross Weight: 2945g(with 3G, GPS)
SPECIFICATIONS
Item | Introduction | |
Operating system | Linux (2.6) | |
Video compression format | H.264 main profile. DSP high-performance processor | |
OSD | Support logo, time, date, vehicle ID etc. as video | |
GUI | OSD interface | Set system parameters by remote control |
Videoandvideosystem | Video input | 1~4CH CVBS video input, 1.0Vp-p, 75Ω |
Video output | 1CH CVBS video output, 1.0Vp-p, 75Ω | |
Preview | Support 1CH and 4CH | |
Resolution | CIF,HD1,D1,720P optional, support up to 2CH D1 and 2CH 720P | |
Video quality | Quality 1~4 optional, quality1 is highest, quality4 is lowest | |
Recording Rate | PAL: 100f/s , CCIR625 line,50 fields NTSC: 120f/s, CCIR525 line,60 fields CIF: 256Kbps ~ 1.5Mbps, quality 1~4 optional HD1: 600Kbps ~ 2.5Mbps, quality 1~4 optional D1: 800Kbps ~ 3Mbps, quality 1~4 optional | |
Videostreaming | ISO14496-10 standard | |
Recording mode | Automatic recording, timer recording, alarm recording | |
Audio | Audio input | 4CH input |
Audio output | 1CH output | |
Compression format | G.726, Rate 5KB/s | |
Alarm | Alarm input | 6CH alarm input(Level input) |
Alarm video file begins to be saved for 10 seconds before alarm, and the time of alarm video file can be set from 30 to 1000 seconds. | ||
Alarm output | 1CH alarm output(Relayoutput) | |
Communication interface | RS232,RJ45 10M/100M adaptivenetwork interface | |
GPS ,G-sensor | Support built-in G-sensor and external GPS | |
Video storage | SD card /Hard drive | 1 piece of 2.5-inch hard drive and SD card |
Firmware upgrade | SD card/ hard drive upgrade | |
Fileformat/system | ASF/ FAT32 | |
Video playback | Video search | Search video files according to recording time, recording mode (alarm, normal) and video storage device etc. |
Playback | Maximum support 4CH simultaneous playback, and analyzevehicle information, support fast forward, rewind, play and pause | |
Support 2/4/8/16 times fast forward and rewind | ||
Power | Power management | 1, Key start/shutdowm DVR: Start/shutdowm DVR according to vehicle key signal, it can also be set to delay shutdown. 2, Timer start/shutdowm DVR. |
Inputvoltage | DC:+8V ~ +36V | |
Outputvoltage | +12V*2A;+5V*0.5A | |
Power-downprotection | UPS technology can save complete video files and ensure those files are not damaged when power-down suddenly. | |
Powerconsumption | Normal operation<10W; Standby<0.5W | |
Work environment | Temperature | -25°C ~ +70°C |
Humidity | 20% to 80% | |
Security management | Passwordaccess | User password and administrator password |
