UNICABLE LNB twin LNB universal lnb from china with cheap price
- Category: >>>
- Supplier: Shenzhen Huayue Technology Co. Limited
Share on (60420879305):
Product Overview
Description
UNICABLE LNB twin LNB universal lnb from china with cheap price
Product Description
| Technical Specifications | ||
| ITEM | SPECIFICATION | UNIT |
| RF Low Band I/P Frequency Range | 10.7 ~ 11.7 | GHz |
| O/P Frequency Range | 950 ~ 1950 | MHz |
| LO Frequency | 9.75 | GHz |
| Noise Figure 25℃ | 1.0(max) | dB |
| RF High Band I/P Frequency Range | 11.7-12.75 | GHz |
| O/P Frequency Range | 1100-2150 | MHz |
| LO Frequency | 10.6 | GHz |
| Noise Figure 25℃ | 1.0(max) | dB |
| LO Initial Accuracy | ±1 | MHz |
| LO Temperature Drift | ±2.5 | MHz |
| Current | 120(max) | mA |
| LO Phase Noise @ 10K Hz | -80(min) | dBc / Hz |
| cross-talk Isolation | 55-65 | dB |
| Legacy Conversion Gain | 53(min) | dB |
| O/P 1dB Compression Point | 0(min) | dBm |
| Image Rejection | 40 (min) | dB |
| SCR LO Phase noise | -80(min) | dBm |
| SCR Conversion Gain | 57(min) | dBm |
| 0K/22K Switch | 150~350 | mV |
| Working Temperature | - 35 ~ + 70 | ℃ |
| Interference | -45 (min) | dB |
| 22K Spurious | -45dBc@22KHz(max) | MHz |
| V/27 H Switch | 14 to 16 | v |
| DC OSC | 55(min) | mv |
| Gain Flatness over any 24MHz band(pk-pk) | 1(max) | dB |
| VSWR | 2.5:1(max) | dB |
| SCR Isolation | 20(min) | dB |
| SCR Gain Flatness | 8(max) | dB |
| SCR Spurious | -45(max) | dB |
Input Frequency Range | LOW Band:10.7~11.7GHz |
| High Band:11.7~12.75GHz |
Output Frequency Range | Low Band: 950 - 2050MHz |
| High Band: 1100 - 2150MHz |
Input VSWR | 2.5:1 |
Output VSWR | 2.5:1 |
L.O. Frequency | Low Band 9.75GHz |
| High Band 10.6GHz |
L.O. Stability | ±2MHz @ (-40c~70c) |
L.O. Phase Noise | -70dBc/Hz (1KHz Offset) |
| -90dBc/Hz (10KHz Offset) |
| -110dBc/Hz (100KHz Offset) |
Conversion Gain | 60dB (TYP) |
Gain Flatness | ±0.5dB/6MHz; ±2.5dB/IN BAND |
Noise Figure | ±0.3dB (Typ) |
Image Rejection | 50dB(Typ) |
Output Power | +5dB (Min) (at 1dB gain compression) |
Cross Polarization Discrimination | 23dB(Min) |
DC SUPPLY VOLTAGE | 11~14.5V (V),15.5~22V (H) |
SUPPLY CURRENT | 130mA (MAX) |
LOW/HIGH BAND SWITCHING | Low Band: 0Hz HIGH BAND: 22KHz±4KHz |
Output Connector | 75Ω "F" type female |
RELATIVE HUMIDITY | 0%~95% |
Operating Temperature | -30 °C to +70 °C |
Packing:
1* Single Universal LNB
Company Information
Our Services
1) We have professional research team. All products are designed buy ourself, so we are experiened in any doubts you have on the product.
2) As a manufacturer, we have our own factory, so we definitely have price advantage on our models!
3) All products are 100% tested working before sent to you.
4) We have professional sales team, so please do not hesitate to contact us if you have any question!
Packaging & Shipping
FAQ
FAQ
Q1: What's your warranty policy?
A1: For all the products, we have one-year warranty. All of our goods are 100% tested working and perfect before sent to you. In case there are unexpected damages during delivery, please do check before you sign for the package.
If you have broken boxes,you can collect them together and send them back to us by post/mail,we will try to repair them for you firstly,if can not repair,we will send you the new motherboard to you to change it.
Q2: What's your minimum order quantity?
A2: Our MOQ is not the same based on different items. Small orders are also welcome, but the unit price is also difference from wholesale price.
Q3: What package do you use for the products?
A3: Usually we have professional retail package for the products. Customized package are also available based on certain MOQ.
Q4: Will your product work in my country?
A4: All of our products are compatible to the international standards, please be subject to the type of network in your country (the band).
Q5: Can I print my own brand logo on your product?
A5: OEM orders are highly welcome. Please write us the details of your logo color, logo position, user manual and box design (if you have) before you send us inquiry. In this way we can offer you most accurate answer at the first time.
Q6: What's your charger standard? Are they available in my country?
A6: Usually we have EU plug, US plug, UK plug and AU plug. Please wirte us your charger standard before you send the inquiry.
Q7: Do you have technical instructions if I buy your product?
A7: Please read the user manual carefully for your reference, we have detail instruction on it. If your problems still can not be solved, welcome to contact us for help. We will also send you update software regularly if you need.
Q8: What payment terms do you have?
A8: For small orders, we usually prefer Paypal and Western Union; for the item that are in stock,we accept 100% bank transfer,will send out the goods ASAP received your payment;
for items that are not in stock, we charge 30% deposit and will ship goods out before the 70% balance are received.
Q9:Can i watch all of the channel programs?
A9:This is the satellite receiver/android tv box/DVB-C TV BOX,only can watch the free air program,if you want to watch the not free programs,you must buy an account from your local service.
Q10: I am very satisfied after I read your FAQ, how can I start to purchase my order?
A10: Please click the "send" at the bottom of this page or contact our sales on Trade Manage online!
