Product Overview
Description
Yuchai generator stirling engine for sale made in china
Product Overview
1) Brand-new engine,w/start motor.
2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.
3) Auto control panel with LCD display.
4) Engine mounted battery-charging alternator,Genset with battery charge of main supply.
5) Circuit Breaker,Exhaust Silencer.
6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard.
7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.
8) Skid-mounted bottom 8 hours fuel tank.
9) Extemal recessed emergency stop button for extra safety.
10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system.
| Genset Model | BYC-280 |
| Prime Power(Kva/Kw) | 225KW/280KVA |
| Structure type | Open/Silent |
| Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Engine Model | YC6M360L-D20 |
| Alternator Model | STG274J0 |
| DimensionL*W*H(mm) | |
| Open Type | 3080*1140*1750 |
| Weight | 2390 |
| Silent Type | 3180*1240*1850 |
| Weight(Kg) | 2500 |
| Engine Detail | |
| Engine Brand | Yuchai Diesel engine |
| Model | YC6M360L-D20 |
| Engine speed | 1800rpm |
| Engine power | |
| …………Standby power | 264KW |
| …………Prime power | 240KW |
| Type | 4cycle,in-line,6-cylinder |
| Aspiration | Turbocharged, |
| Governor | electrical |
| Bore*Stroke | 120*145mm |
| Displacement | 9.839 Litres |
| Compression ratio | 17:01 |
| Alternator Detail | |
| Manufacturer | Fuzhou Boomaster Power Co.,Ltd |
| Model | STG274J0 |
| Output power | 225KW |
| Number of phase | 3 |
| Power factor(Cos Phi) | 0.8 |
| Altitude | ≤1000m |
| Overspeed | 2250rpm |
| Number of Pole | 4 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | ±0.5% |
| Sustained short circuit current | 300%(3IN):10s |
| Total haarmonics (TGH/THC) | <4% |
| Wave form:Nema=TIF | <50 |
| Wave form:I.E.C=THF | <2% |
| Bearing | single |
| Coupling | Direct |
Generator optional:
Engine | Heater | Battery Charger |
|
Fuel System | Daily Fuel Tank | Base Fuel Tank |
|
Control System | Auto Control Panel | Remote Control Panel | Auto Transfer Switch (ATS) Control Panel |
Alternator | Single phase, three phase | Brushless, carbon brush |
|
Type | Weatherproof Type | Soundproof Type | Trailer type |
Spare Parts | Fuel filer, Oil filter, air filter, tank pad, Triangle Belt, tools and Engine Parts Drawing List | ||
Generator set warranty and maintenance:
Ø Do the full power load test for five hours before package.
Ø One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.
Ø After expiration, we provide spare parts maintenance with low price
