QJ series deep well submersible water pump for farm irrigation pump

Product introduction:
1. QJ 4inch vertical deep well centrifugal water pump stainless steel submersible pump is simple structure, easy installation, convenient operation and maintenance.
2. Pump is equipped with inner motor, and special designed for whole submerge work. (Electrical machine and pump wok as a whole, it's safe very much.)
3. It is suitable to transport water for extraction of deep groundwater, can also be used in deep well, rivers, reservoirs and ditch water projects.
4. It is mainly used for irrigation and livestock water system, also for city, factory, railways, mining, water supply and drainage construction site.
5. Stainless steel submersible pump for models less than DN100mm(4inch) and cast iron pumps for models with larger diameter.


Working Principle:
Submersible, Multi-stage
Main applications:
Water
Driver:
Electric motor
Power Specs:
220/380/415V 3phase; 110/220/240V 1phase, 50hz/60hz
Max.permissible fluid temperature:
80°C(176°F)
Type of connection:
Flange
Installation position:
Vertical
Casing/Inner parts material:
Cast iron,Stainless steel /Cast iron, Stainless steel
Shaft seal type:
Mechanical seal
Free passage:
0.1 mm
Maximum drive rating:
185KW(250HP)
Maximum discharge caliber:
150mm(6inch)
Maximum discharge-side pressure:
2.8MPa(28bar)
Maximum head:
280m(918.4ft)
Flow rate range:
5-300m3/h(22-1320US.GPM)
