This Electric bike motor automatic induction motor winding machine equips with servo control system. It can diagnose fault, count output, etc. Other function such as auto winding, multi-diameter wires winding, auto indexing, auto skip slot and winding speed could be programmed in the touch screen. This machine is easy to operate and maintain.

Technical parameter:

Wire diameter: 0.3~1.5mm

Stator diameter: 90~100mm

Slot number 8~63

Winding number: 1~13 pcs

Stator height: 0~50mm

Winding speed 200rpm/min

Power supply: 220V/ 50/60Hz 1.5Kw

Weight: 900Kg

Dimension: 1700*950*2000mm

Machine structure and working Principle

This automatic induction motor winding machine is consisted of machine body, indexing part, winding and wire array part winding and wire array part wire threading part, tensioner and control system. The winding, arraying and indexing are driven by servo motor controlled by control system

Maintenance

Every day check the mechanical, electrical, pneumatic and lubricating parts before work. Check if the fastener are loosen, abnormal noise in the moving parts or if the electrical parts can work normally.

After work, clean the machine and reset the machine.

Check if there is water in the air source filler regularly. If yes, drain away water.

Check if there is oil in the atomized lubricator regularly. If no, add oil.

Check the lubricating condition of guide way mechanism regularly.

Check the magnet valve screws and its pipe connector every 3 months

Clean the filler every 2 months

Calibrate the pressure gage every 1 year
