ICC NDIR Gas Modules IR A0 Series, High precision, Using dual channel pyroelectric infrared detector
- Category: >>>
- Supplier: Qinhuangdao Intrinsic Crystal Technology Co. Ltd.
Share on (60426365478):
Product Overview
Description
Products Show
Series: IR-A0
Using area: Detecting instrument
Features: Using dual channel pyroelectric infrared detector, high sensitivity, high resolution, excellent stability, various interface
Using area: Detecting instrument
Features: Using dual channel pyroelectric infrared detector, high sensitivity, high resolution, excellent stability, various interface
Product Paramenter
Structure | Dual beam |
Working temperature | -20 to+70°C |
Operating Voltage and current | 9-24VDC,≤120mA(Average), ≤300mA(Maximum) |
Response time (t90) | ≤60s |
Calibration | No need for on-site calibration Guarantee the real time detection accuracy |
Range | 0~1500ppm, 0~5000ppm Or customization |
Detection accuracy | ±10ppm±2% * readout |
Gas input type | Diffusion |
Gas kind | SF6, CH4, CO2, NOx, CO, etc. |
Signal output | UART,485, PWM, IIC, 4-20mA, Analog 0.6-3V, etc |
Company Profile
Exhibition Display
Certificate Display
Shipping Methods
FAQ
1. Product choosing
Our company have the large quantity of standard products in our stocks. Customer can choose the products according to the
acquirement, such as size, technical data and Coating characteristics. Also, we can produce the special optical products according
customers’ demand.
2. Product preserving
Optical components should be protected with dry situation and suitable temperature without being used. Please clean it with gauze
and cotton dipped in special cleaner (20% anhydrous alcohol + 80% ether mixture)
3. Quality assurance
Please check out the products when you received with the courier being attendance. Within 30 days after receiving the products,
you can contact me freely and provide your testing report if there is something unartificial damage and disqualification technical
data. We will be responsible for free charge repairmen, change and return.
4. Payment terms
The payment terms can be flexible and can be cash, T/T and Paypal.
5. Delivery terms
We can deliver stock products within 7 work days, and within promissory delivery time for customized products.
Our company have the large quantity of standard products in our stocks. Customer can choose the products according to the
acquirement, such as size, technical data and Coating characteristics. Also, we can produce the special optical products according
customers’ demand.
2. Product preserving
Optical components should be protected with dry situation and suitable temperature without being used. Please clean it with gauze
and cotton dipped in special cleaner (20% anhydrous alcohol + 80% ether mixture)
3. Quality assurance
Please check out the products when you received with the courier being attendance. Within 30 days after receiving the products,
you can contact me freely and provide your testing report if there is something unartificial damage and disqualification technical
data. We will be responsible for free charge repairmen, change and return.
4. Payment terms
The payment terms can be flexible and can be cash, T/T and Paypal.
5. Delivery terms
We can deliver stock products within 7 work days, and within promissory delivery time for customized products.
