Product Overview

Description





 If you have any question please  contact  us



We can supply  Non-insulated Spade Terminals  Screw on Wire Connector  Insulated Hook Terminals ,Closed-End Connectors, connector, cable connector, wire connector, insulated ring terminals, fork pre-insulated terminals, pin pre-insulated terminals and pipe pre-insulated terminals. We can provide good quality and good service with competitive prices.

















ITEM NO	Color	Dimension(mm)		A.W.G
		Inner diameter	length
SST-S11	white	1.7	26	26-24
SST-S21	red	2.7	40	22-18
SST-S31	blue	4.5	40	16-14
SST-S41	yellow	6	40	12-10
Working temperature: - 55°C~125°C
Minimum contraction temperature: 80°C
Solder began to melt temperature: 138°C
Solder completely melt temperature: 160°C
